onsemi 3 CMOS Multiplexer/Demultiplexer Bus Switch, 16-Pin SOIC MC14053BDR2G

The onsemi MC14053BDR2G is a high-performance multiplexer/demultiplexer bus switch integrating 3 CMOS elements within a 16-pin SOIC surface mount package. This device is designed for use in industrial, automotive, and electronic systems requiring reliable multiplexing and demultiplexing of signals.

Built on CMOS logic family technology, the MC14053BDR2G offers low power consumption across a wide operating voltage range of 3 to 18 volts. It features a maximum on-state resistance of 1.2 kΩ, ensuring minimal signal loss while switching. The device operates efficiently over a wide temperature range from -55°C to 125°C, making it suitable for harsh environments including automotive applications compliant with AEC-Q100 standards.

The compact 16-pin SOIC package measures 10 mm in length, 4 mm in width, and 1.5 mm in height, allowing for efficient PCB space utilization. This multiplexer/demultiplexer bus switch is ideal for electronic circuit designs requiring reliable switching and bus management in computing, communications, and control systems.

Key features include the integration of 3 elements per chip enabling versatile signal routing with CMOS output type compatibility. The surface mount mount type simplifies assembly and enhances device reliability in modern electronics manufacturing.

Features CMOS logic family technology ensuring low power consumption. Operates within a wide supply voltage range of 3 to 18 volts. Contains 3 elements per chip supporting multiplexing and demultiplexing functions. Designed with 16-pin SOIC surface mount package for compact PCB integration.

Supports operating temperature range from -55°C to 125°C for reliable industrial use. Maximum on-state resistance is 1.2 kΩ enhancing signal integrity. Complies with automotive standard AEC-Q100 ensuring high quality and durability.

Physical dimensions: 10 mm length, 4 mm width, and 1.5 mm height for space-constrained designs.

This multiplexer/demultiplexer IC from onsemi is suited for industrial automation, automotive electronics, communication equipment, and other electronic applications requiring robust multiplexer switching. Explore related Semiconductor components and designs with confidence on EnvMart.
