Maxim Integrated Multiplexer 4 CMOS Quad SPST 16-Pin TSSOP MAX14758EUE+

Maxim Integrated MAX14758EUE+ is a high-performance multiplexer IC featuring 4 CMOS quad SPST switches in a compact 16-pin TSSOP package. It supports single-supply operation from +10V to +70V as well as bipolar-supply operation up to ±35V, making it suitable for a wide range of electronic circuit designs.

The device exhibits a maximum on-state resistance of 10 ohms and a flatness of 0.004 ohms, ensuring minimal signal loss. Off-leakage currents are minimal at 2.5nA typical even at elevated temperatures (+85°C), which contributes to reduced power consumption in sensitive applications.

Protection diodes provide robust overvoltage and undervoltage clamping, enhancing device reliability in harsh electrical environments. The typical supply current is only 500µA, enabling efficient operation in battery-powered or low-power systems.

Mounting type is surface mount with package dimensions of 5.1mm length, 4.5mm width, and 950µm height. The temperature range extends from an operating minimum of -40°C up to +85°C ambient, with functional operation guaranteed up to +125°C.

This multiplexer is functionally compatible with industry-standard devices DG411, DG412, and DG413, offering ease of integration. It is RoHS compliant, meeting environmental safety standards.

Typical applications include ATE systems, audio signal routing and switching, battery management, environmental control, industrial control systems, instrumentation, and medical systems. This makes it an ideal choice for diverse industrial, laboratory, and electronic manufacturing uses.

Maxim Integrated provides reliable semiconductor components known for quality and performance. This multiplexer supports advanced signal routing demands with high voltage range and low power operation.

Browse the Electronics & Electricals category at EnvMart for more Multiplexer ICs and related semiconductor solutions curated for industrial and commercial requirements. Operates with single supply voltage from +10V to +70V.

Bipolar supply operation up to ±35V provides design flexibility. Maximum on-state resistance of 10 ohms ensures efficient signal conduction. Low off-leakage current of 2.5nA at +85°C for reduced power consumption. Includes overvoltage and undervoltage clamping protection diodes.

Typical supply current of 500µA supports low power applications. Temperature range from -40°C to +85°C (functional to +125°C) for robust operation. Package dimensions: 5.1mm length, 4.5mm width, 950µm height. Functionally compatible with DG411, DG412, and DG413 multiplexers.

RoHS compliant for environmental safety.
