Vishay 120 V 35 A Surface Mount Rectifier & Schottky Diode TO-252 Package Type Schottky 3-Pin DPAK V35PW12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 13in |
| Brand | Vishay |
| Height | 1.3mm |
| Length | 6.1mm |
| Model | V35PW12HM3/I |
| Width | 6.1mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS, UL 94 V-0, AEC-Q101 |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 35A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 60mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 260A |
| Maximum Forward Voltage Vf | 1.05V |
Key Features
- Features low forward voltage drop for high efficiency operation.
- Designed as a surface-mount device in a TO-252 package for compact PCB integration.
- Supports a peak non-repetitive forward surge current of 260 A.
- Operates reliably within a temperature range from -40°C to 150°C.
- Configured as a single diode with 3 pins in DPAK format.
- Complies with automotive standard AEC-Q101 for high reliability.
- Ideal for use in low voltage high frequency DC/DC converters and polarity protection.
- RoHS compliant and meets UL 94 V-0 standards for safety.
Product Description
Vishay V35PW12HM3/I is a high current density surface-mount rectifier and Schottky diode featuring trench MOS Schottky technology that offers low forward voltage drop and high efficiency.
Encapsulated in a low-profile TO-252 DPAK package measuring approximately 6.1 mm in length and width with a height of 1.3 mm, this diode is suitable for compact PCB layouts and automated placement, meeting MSL level 1 standards.
It provides a maximum continuous forward current of 35 A and can withstand peak reverse repetitive voltages up to 120 V, with a peak non-repetitive forward surge current rating of 260 A, ensuring robustness in demanding electrical conditions.
The device operates reliably over a broad temperature range from -40°C to 150°C, making it suitable for industrial, automotive, and power supply applications including DC/DC converters, freewheeling diodes, and polarity protection circuits.
Certification and quality standards met include RoHS compliance, UL 94 V-0 flammability rating, and AEC-Q101 automotive qualification, endorsing the device's suitability for automotive and other high-reliability environments.
Features low forward voltage drop for efficiency and reduced power losses. Surface mount TO-252 package supports automated manufacturing processes. Automotive grade with AEC-Q101 compliance for enhanced reliability. Designed for high frequency switching power supplies and protection circuits.
Compact dimensions enable use in space-constrained electronic designs. Meets strict environmental and safety standards.
This Vishay Schottky diode model V35PW12HM3/I offers robust electrical performance and reliability for demanding semiconductor applications in electronics manufacturing, industrial automation, automotive, and power electronics sectors.
Explore our comprehensive range of semiconductor components at EnvMart for high-quality electronic solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay V35PW12HM3/I Schottky diode is 35 A.
This model can withstand a peak reverse repetitive voltage of up to 120 V.
The TO-252 package measures approximately 6.1 mm in length and width, with a height of 1.3 mm.
It operates reliably within a temperature range from -40°C to 150°C.
The peak non-repetitive forward surge current rating is 260 A.
Yes, it complies with the automotive standard AEC-Q101, ensuring high reliability.
The diode is RoHS compliant and meets UL 94 V-0 standards for safety.
This model is configured as a single diode with 3 pins in DPAK format.
The maximum forward voltage drop is 1.05 V.
It is ideal for use in low voltage high frequency DC/DC converters and polarity protection circuits.
This diode uses a surface mount type for compact PCB integration.
The peak reverse current rating is 60 mA.
