TDK SIMID 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±10% 320 mA DC 28 MHz B82432C1103K000

Free Delivery in India | Lowest Global Shipping Charges

TDK SIMID 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±10% 320 mA DC 28 MHz B82432C1103K000



Category Surface Mount Inductors Brand TDK Condition New

Specifications

Country of Origin	Hungary
Brand	TDK
Height	3.2mm
Length	4.5mm
Model	B82432C1103K000
Depth	3.2mm
Packaging	Tape & Reel
Series	SIMID
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-55°C
Core Material	Ferrite
Inductance	10μH
Standards/Approvals	RoHS
Package/Case	1812
Maximum DC Current	320mA
Pin Count	2
Maximum DC Resistance	980mΩ
Inductance Tolerance	±10 %
Termination Style	Solder
Maximum Self Resonant Frequency	28MHz
Minimum Quality Factor	40
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

Compact 1812 package size with 4.5 mm length and 3.2 mm height and depth.
High quality factor of 40 for efficient filtering performance.
Operates within -55°C to 150°C, certified to AEC-Q200 automotive standard.
Low DC resistance of 980 milliohms for reduced power loss.
Shielded design minimizes electromagnetic interference.
Solder termination style suitable for surface mounting on PCBs.
Ferrite core material enhances magnetic properties.
Manufactured in Hungary and RoHS compliant.

Product Description

TDK B82432C1103K000 is a shielded wirewound surface mount inductor designed with a ferrite core, offering an inductance of 10 μH with a tolerance of ±10%. It supports a maximum DC current of 320 mA and has a high quality factor of 40, ensuring superior performance in electrical noise filtering and energy storage applications.

The inductor comes in a 1812 package case with precise dimensions of 4.5 mm length and 3.2 mm height and depth. Its solder termination style allows for efficient and reliable surface mounting on printed circuit boards (PCBs).

Engineered to operate within a broad temperature range from -55°C to 150°C, this component complies with the AEC-Q200 automotive standard, making it suitable for automotive electronics as well as telecommunications and industrial environments.

The device exhibits a low DC resistance of 980 milliohms, reducing power loss while maintaining stable operation. The ferrite core material enhances magnetic performance and contributes to the shielding effectiveness, which minimizes electromagnetic interference in sensitive circuits.

Produced in Hungary, this RoHS compliant inductor supports advanced applications such as filtering of supply voltages, coupling and decoupling signals, antenna systems, and various industrial electronic systems.

Compact 1812 package ensuring ease of PCB integration. High quality factor for efficient electrical performance. Wide operating temperature range suitable for harsh conditions. RoHS compliance supports environmental standards.

Shielded design reduces electromagnetic interference.

For engineers and designers, the B82432C1103K000 SIMID Series inductor from TDK is a reliable choice for improving circuit performance in demanding electronic systems. Explore additional Surface Mount Inductors in the Electronics Components category at EnvMart to find compatible solutions for your projects.
