TDK Shielded Wirewound Surface Mount Inductor, Ferrite Core, 22 μH ±20%, 1.8 A, 6045 Package, CLF6045NI-D

Free Delivery in India | Lowest Global Shipping Charges

TDK Shielded Wirewound Surface Mount Inductor, Ferrite Core, 22 μH ±20%, 1.8 A, 6045 Package, CLF6045NI-D



Category Surface Mount Inductors Brand TDK Condition New

Specifications

Country of Origin	India
Diameter	6mm
Brand	TDK
Height	4.5mm
Length	6.3mm
Model	CLF6045NI-D
Depth	6mm
Packaging	Tape & Reel
Series	CLF6045NI-D
Maximum Operating Temperature	150°C
Minimum Operating Temperature	-55°C
Core Material	Ferrite
Inductance	22μH
Standards/Approvals	RoHS
Package/Case	6045
Maximum DC Current	1.8A
Maximum DC Resistance	75mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	100kHz
Inductor Construction	Shielded
Automotive Standard	AEC-Q200

Key Features

Shielded wirewound surface mount inductor supporting up to 1.8 A DC current.
Featuring 22 μH inductance ±20% tolerance for precision circuit applications.
Constructed with a ferrite core and designed for high mechanical robustness.
AEC-Q200 automotive standard ensuring reliability under demanding conditions.
Operates within a broad temperature range from -55°C up to +150°C.
Low DC resistance of 75 mΩ offers efficient power handling.
Compact 6.3 mm length, 6 mm width and 4.5 mm height, suitable for PCB integration.
Ideal for DC/DC converters, automotive electronics, and filtering tasks.

Product Description

The TDK CLF6045NI-D is a shielded wirewound surface mount inductor designed for advanced electronic circuitry, offering robust performance and reliability.

With an inductance of 22 μH (±20% tolerance) and rated for up to 1.8 A direct current, this component is suitable for a wide range of power and signal applications including DC/DC converters, voltage filtering, and automotive electronics. Its construction using a ferrite core ensures strong shielding and minimizes electromagnetic interference, enabling optimal signal integrity in dense PCB environments.

Engineered to meet the AEC-Q200 automotive standard, the CLF6045NI-D inductor emphasizes mechanical robustness and consistent performance across a broad temperature spectrum from -55°C to +150°C. Its low DC resistance (75 mΩ) allows for efficient energy transfer and reduced power losses in demanding circuits. The compact package dimensions (length 6.3 mm, width 6 mm, height 4.5 mm) enable easy integration into modern high-density printed circuit boards.

This inductor features shielded construction for improved EMI suppression and offers a maximum self resonant frequency of 100 kHz. Its surface mount termination style, along with tape & reel packaging, supports rapid automated assembly processes in industrial manufacturing.

Applications include automotive electronics, power conversion modules, voltage filtering, coupling and decoupling functions, and other advanced electronic system requirements. With RoHS compliance, the CLF6045NI-D also meets industry standards for environmental health and safety.

TDK is recognized globally for quality passive electronic components. Explore the Surface Mount Inductors category to find additional sizes and values for diverse electronic and power management projects.
