TDK NLCV-EF Series Shielded Wirewound Surface Mount Inductor, Ferrite Core, 1μH ±20%, 475mA Idc, 1008 Package NLCV25T-1R0M-EF

Free Delivery in India | Lowest Global Shipping Charges

TDK NLCV-EF Series Shielded Wirewound Surface Mount Inductor, Ferrite Core, 1μH ±20%, 475mA Idc, 1008 Package NLCV25T-1R0M-EF



Category Surface Mount Inductors Brand TDK Condition New

Specifications

Country of Origin	Japan
Brand	TDK
Height	1.8mm
Operating Temperature Range	- 40 to +105°C (including self-temperature rise)
Length	2.5mm
Model	NLCV25T-1R0M-EF
Depth	2mm
Packaging	Tape & Reel
Series	NLCV-EF
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	1μH
Standards/Approvals	RoHS
Package/Case	1008
Maximum DC Current	475mA
Maximum DC Resistance	442mΩ
Inductance Tolerance	±20 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	200MHz
Minimum Quality Factor	20
Inductor Construction	Wirewound

Key Features

Designed for decoupling circuits in electronic devices.
Ferrite core construction provides excellent shielding.
1μH inductance rated at 475mA maximum DC current.
Surface mount 1008 package for integration on PCB.
Operating temperature range from -40°C to 105°C including self-temperature rise.
Resin molded body ensures durability and stable performance.
RoHS compliant for environmental safety.
Ideal for smart meters, AV equipment, communications infrastructure, and industrial electronics.

Product Description

The TDK NLCV25T-1R0M-EF is a shielded wirewound surface mount inductor featuring a ferrite core and a compact 1008 package. This component is engineered for use in decoupling circuits and electronic devices requiring reliable inductive performance and good EMI suppression.

With a 1μH inductance value and ±20% tolerance, the inductor can handle up to 475mA maximum DC current, making it suitable for high-density PCB designs and critical communication equipment. The resin molded structure and ferrite core combine to deliver robust shielding and stable operating behavior.

This surface mount inductor is RoHS compliant, ensuring environmental safety. Its termination style is specifically optimized for surface mount configurations, enabling automated placement in industrial manufacturing. The unit operates in a wide temperature range from -40°C to 105°C, which includes self-temperature rise, supporting both indoor and outdoor electronics.

The NLCV-EF series is widely used in applications such as smart meters, audio-video equipment, xDSL modems, mobile base stations, communication infrastructure devices, and a broad variety of industrial electronics. Its combination of high quality factor, maximum self resonant frequency of 200MHz, and a DC resistance of 442mΩ optimize its performance in demanding environments.

Moulded and shielded for durability, the inductor provides low-profile dimensions with a 2.5mm length, 2mm depth, and 1.8mm height, facilitating its integration in miniaturized circuits. The packaging is supplied in tape & reel format for efficient production workflows.

Designed for decoupling circuits in electronic devices. Ferrite core construction provides excellent shielding. 1μH inductance rated at 475mA maximum DC current. Surface mount 1008 package for integration on PCB. Operating temperature range from -40°C to 105°C including self-temperature rise.

Resin molded body ensures durability and stable performance. RoHS compliant for environmental safety. Ideal for smart meters, AV equipment, communications infrastructure, and industrial electronics. Explore related Surface Mount Inductors from TDK in the Electronics & Electricals category at EnvMart for advanced circuit solutions.
