TDK 6.8μH 1210 Unshielded Wirewound Surface Mount Inductor, Ferrite Core, 135mA Idc ±10% B82422A1682K100

Free Delivery in India | Lowest Global Shipping Charges

TDK 6.8μH 1210 Unshielded Wirewound Surface Mount Inductor, Ferrite Core, 135mA Idc ±10% B82422A1682K100



Category Surface Mount Inductors Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	2mm
Length	3.2mm
Model	B82422A1682K100
Depth	2.5mm
Packaging	Tape & Reel
Series	B82422A*100
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Core Material	Ferrite
Inductance	6.8μH
Standards/Approvals	RoHS
Package/Case	1210
Maximum DC Current	135mA
Pin Count	2
Maximum DC Resistance	2.8Ω
Inductance Tolerance	±10 %
Termination Style	Solder
Maximum Self Resonant Frequency	90MHz
Minimum Quality Factor	27
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200

Key Features

6.8μH surface mount wirewound inductor with ferrite core.
Compact 1210 package for high-density PCB layouts.
Handles up to 135mA maximum DC current and ±10% inductance tolerance.
Unshielded, molded SMD construction with two-pin configuration.
AEC-Q200 automotive standard and RoHS compliant for reliable quality.
Maximum DC resistance of 2.8Ω and self-resonant frequency of 90MHz.
Wide operating temperature range from -55°C to +125°C.

Product Description

The TDK B82422A1682K100 is a compact, high-performance wirewound surface mount inductor specifically engineered for a wide range of electronic circuitry requiring efficient signal filtering and energy storage in space-constrained environments. With an inductance of 6.8μH and housed in a standard 1210 (3.2mm × 2.5mm × 2.0mm) package, this inductor is ideal for use in high-density, automated PCB assembly processes.

This unshielded inductor features a ferrite core and a molded construction, supporting a maximum DC current of 135mA and a maximum DC resistance of 2.8Ω, ensuring stable power delivery while minimizing energy loss. The SMD inductor is compliant with AEC-Q200 automotive standards, making it suitable for demanding automotive, industrial, and consumer electronic applications where reliability and performance are critical.

Its robust design supports operation over a wide temperature range, from -55°C to +125°C, enabling reliable performance in harsh environments. With a high quality factor of 27 (Q:27 min), and a self-resonant frequency of 90MHz, the B82422A1682K100 provides effective attenuation of noise and ripple across broad frequency ranges. Its ±10% inductance tolerance guarantees consistent operation within technical specifications.

The 1210 inductor is designed for reflow and wave soldering techniques and features a solder termination style for straightforward assembly. With two terminals, it integrates easily into modern SMD production lines for applications including DC-DC converters, power supplies, signal filtering, and RF circuits.

Ideal use cases include automotive electronics, industrial automation, telecommunications equipment, consumer electronics, and any high-reliability SMD circuit requiring compact and efficient inductors. Thanks to RoHS compliance, the component also aligns with current environmental and safety regulations.
