Vishay 1 kV 1 A General Purpose Surface Mount Diode 2-Pin DO-214AC US1M-E3/5AT

Vishay US1M-E3/5AT is a general purpose surface mount diode designed for high reliability in electronic and power applications. It features a compact 2-pin DO-214AC package with matte tin plated leads that are easily solderable and compatible with automated assembly lines. The diode supports a maximum continuous forward current of 1 ampere and withstands a peak reverse repetitive voltage of 1 kV, making it suitable for medium-power circuits.

The device uses a glass passivated chip junction that enhances reverse voltage resistance and minimizes leakage currents, resulting in efficient and dependable operation. With an ultrafast reverse recovery time of 75 nanoseconds, this diode is optimized for switching mode inverters, converters, and freewheeling applications where fast switching speeds and low losses are critical.

The operating temperature range from -55°C to 150°C allows use in a variety of industrial, telecommunications, computing, and consumer electronic environments. The diode is qualified to AEC-Q101 automotive standards, ensuring robustness and performance in automotive electronics and high-reliability systems.

Typical applications include switching mode power supplies, high frequency switching circuits, automotive power electronics, and telecommunications equipment. The diode also supports surge currents of up to 30 amperes peak non-repetitive forward surge, providing durability in transient conditions.

Surface mount diode in small DO-214AC package with 2 pins. Maximum continuous forward current: 1 A for reliable circuit operation. Peak reverse voltage: 1 kV suitable for high voltage circuits. Ultrafast recovery time of 75 ns for efficient switching performance.

Operating temperature range from -55°C to 150°C for extended environmental use. Matte tin plated leads ensure compatibility with automatic pick-and-place systems. Glass passivated junction enhances voltage resistance and reduces leakage.

AEC-Q101 qualified for automotive-grade reliability. Supports peak non-repetitive forward surge current of 30 A.

This diode is commonly used in the electronics and electrical industry sectors including data communication, automotive electronic systems, power management, and consumer electronic devices. Vishay's reliable manufacturing and quality control ensure consistent device performance suitable for demanding industrial and commercial applications.
