Microchip Voltage Supervisor 3-Pin SC-70 3 V Reset Threshold, Surface Mount TCM809SVLB713

Free Delivery in India | Lowest Global Shipping Charges

Microchip Voltage Supervisor 3-Pin SC-70 3 V Reset Threshold, Surface Mount TCM809SVLB713

Name: Microchip Voltage Supervisor 3-Pin SC-70 3 V Reset Threshold, Surface Mount TCM809SVLB713
Brand: Microchip
SKU: 131039
Price: 0.41 USD
Availability: InStock



Category Voltage Supervisors Brand Microchip Condition New

Specifications

Country of Origin	Thailand
Voltage	Supervisors Microchip 1 Voltage Supervisor 3-Pin 3 V SC-70 RS Stock No
Brand	Microchip
Height	1.1mm
Length	2.25mm
Model	TCM809SVLB713
Width	1.35mm
Mount Type	Surface
Series	TCM809
Maximum Operating Temperature	125°C
Package Type	SC-70
Sub Type	Microcontroller Reset Monitor
Minimum Operating Temperature	-40°C
Pin Count	3
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	1.2V
Number of Supervisors	1
Output Driver	Push Pull, Active Low
Reset Threshold Voltage	3V
Monitored Voltage	2.5V
Reset Active Time	560ms

Key Features

Contains a single supervisor to monitor voltage levels effectively.
Monitors reset threshold at 3 V to ensure proper microcontroller operation.
Offers push-pull, active low output driver for reliable logic signaling.
Operates within a supply voltage range of 1.2 V to 5.5 V.
Surface mountable SC-70 package with compact dimensions of 2.25 mm length and 1.35 mm width.
Functions over an operating temperature range from -40°C to 125°C.
Reset active time of 560 ms guarantees stable reset signals.
Designed to improve system reliability by supervising microcontroller voltage levels.

Product Description

Microchip TCM809SVLB713 is a voltage supervisor device designed for monitoring microcontroller supply voltage to maintain system stability and reliability. This surface-mounted component comes in a compact 3-pin SC-70 package with dimensions of 2.25 mm by 1.35 mm and height of 1.1 mm, allowing it to fit efficiently on printed circuit boards with limited space.

Operating over a wide temperature range from -40°C to 125°C, the TCM809SVLB713 supports voltages from 1.2 V to 5.5 V, and specifically monitors a reset threshold voltage of 3 V. Its push-pull, active low output driver offers clear signaling for system reset conditions without manual intervention or watchdog timer functionalities.

The device enhances microcontroller systems by detecting undervoltage conditions reliably, ensuring the microprocessor is reset appropriately to avoid malfunctioning. It does not include additional features like watchdog timers or power fail detection but focuses on precise voltage supervision.

With a reset active time of 560 milliseconds, it provides stable and reliable reset signals critical for embedded system performance. Single microcontroller reset monitor supervisor. Push-pull output driver, active low logic.

Surface mount SC-70 package for compact PCB designs. Wide operating temperature from -40°C to 125°C. Reset threshold voltage set at 3 V. Minimum supply voltage requirement of 1.2 V. Maximum operating supply voltage of 5.5 V.

Reliable reset active time of 560 ms. Improves embedded system stability and reliability. Ideal for voltage supervision in microprocessor control circuits. Explore our comprehensive selection of semiconductor Voltage Supervisors at EnvMart for your industrial, automotive, and commercial electronics needs.
