STMicroelectronics Microprocessor Supervisory Voltage Supervisor 5-Pin SOT-23, STM6823SWY6F
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Supervisors STMicroelectronics 1 Voltage Supervisor 5-Pin 3 V SOT-23, STM6823SWY |
| Brand | STMicroelectronics |
| Height | 1.15mm |
| Length | 2.9mm |
| Model | STM6823SWY6F |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | STM682 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Sub Type | Microprocessor Supervisory Circuit |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 1V |
| Number of Supervisors | 1 |
| Output Driver | Push Pull, Active Low |
| Reset Threshold Voltage | 3V |
| Monitored Voltage | 2.93V |
| Reset Active Time | 280ms |
Key Features
- Monitors supply voltage with a reset threshold of 3 V to ensure stable operation.
- Includes watchdog timer for system reliability.
- Manual reset functionality for controlled reset operations.
- Output driver is push-pull, active low for efficient signaling.
- Suitable for desktop, laptop, and portable battery-powered equipment.
- Wide operating temperature range from -40°C to 85°C ensures versatility in various environments.
- Compact SOT-23 surface mount package with 5 pins for easy PCB integration.
- Minimum supply voltage of 1 V and maximum of 5.5 V for broad application compatibility.
Product Description
STMicroelectronics STM6823SWY6F is a microprocessor supervisory voltage supervisor IC in a 5-pin SOT-23 surface mount package. It features a monitored voltage of 2.93 V and a reset threshold voltage of 3 V, designed to maintain stable operation of microprocessor systems through power supply voltage supervision and reset functions. This device includes a watchdog timer and manual reset capabilities, with an active-low push-pull output driver ensuring effective signaling during voltage supervision.
The supervisor operates reliably within a temperature range of -40°C to 85°C, offering robust performance for various applications including desktop and portable battery-powered equipment, test and measurement instruments, and multiple-output power supplies. With a minimum supply voltage of 1 V and maximum supply voltage of 5.5 V, it supports diverse power conditions, protecting microprocessor systems from undervoltage conditions.
The compact SOT-23 package, measuring 2.9 mm in length, 1.6 mm in width, and 1.15 mm in height, allows easy integration into PCB assemblies. Its reset active time of 280 ms ensures proper system reset timing. STMicroelectronics' STM6823 series emphasizes supply voltage supervision and reliable system reset functionalities, critical for microprocessor and microcontroller circuit protection.
Monitors microprocessor supply voltage and provides reset and watchdog timer functions. Push-pull, active low output driver for effective system reset signaling. Wide supply voltage range from 1 V to 5.5 V for varied applications.
Operating temperature from -40°C to 85°C suitable for industrial and commercial use. Compact 5-pin SOT-23 package facilitates space-saving PCB design. Reset threshold voltage precision enhances system reliability. Manual reset option for additional control and failsafe operation.
Applicable to computers, portable devices, test instruments, and battery-powered systems. Designed for robust voltage supervision and microprocessor reset solutions.
This voltage supervisor is ideal for industrial, commercial electronics, laboratory equipment, and embedded systems requiring reliable power supply monitoring. It safeguards against low voltage conditions, ensuring microprocessor stability and preventing system errors.
Explore more Voltage Supervisors and related semiconductor components on EnvMart for enhanced system designs and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The reset threshold voltage of this model is 3 V, designed to maintain stable operation of microprocessor systems.
The monitored voltage for this voltage supervisor is 2.93 V, ensuring effective supervision of the power supply.
It operates within a temperature range of -40°C to 85°C, making it suitable for various environments.
This model supports a minimum supply voltage of 1 V and a maximum of 5.5 V, allowing for broad application compatibility.
It features a push-pull, active low output driver, which provides efficient signaling during voltage supervision.
The reset active time is 280 ms, ensuring proper timing for system resets.
This voltage supervisor comes in a compact SOT-23 surface mount package, facilitating easy PCB integration.
It has 5 pins, which supports its compact design and functionality in electronic circuits.
It is suitable for desktop, laptop, and portable battery-powered equipment, as well as test and measurement instruments.
The country of origin for the STM6823SWY6F is India.
This model belongs to the STM682 series, which emphasizes supply voltage supervision and reliable system reset functionalities.
It uses surface mounting, which is common for compact electronic components in PCB assemblies.
