Samtec EHT Series Straight Through Hole Shrouded PCB Header, 24 Contacts, 2 mm Pitch, 2 Rows EHT-112-01-S-D

Samtec EHT-112-01-S-D is a high-quality EHT Series straight through hole shrouded PCB header featuring 24 male contacts arranged in 2 rows with a 2 mm pitch. This PCB header is designed for wire-to-board connection systems requiring robust mechanical and electrical characteristics.

The housing is crafted from liquid crystal polymer, providing excellent durability and stability during operation. Phosphor bronze contact material with gold plating ensures superior conductivity and corrosion resistance, enhancing long-term reliability. The header supports through-hole mounting type with solder termination, facilitating strong PCB attachment.

Operating temperature ranges from -55°C to 125°C make it suitable for varied environmental conditions. Additional design features include a polarization notch and an IDC ejector for secure cable locking and proper orientation. Available pin counts range from 3 to 25 pins, allowing adaptability in various electronic assemblies.

This product is produced in the United States under rigorous quality controls and meets no specific standards or approvals. It is ideal for applications in electronics components manufacturing, PCB assembly, wire harnessing, and power connector solutions.

Features straight orientation with 2 rows for compact layout. Constructed with liquid crystal polymer housing for durability. Contacts are made of phosphor bronze and plated with gold for reliable conductivity. Designed for through hole mount type ensuring secure solder connection.

Operates across a temperature range from -55°C to 125°C. Includes polarization notch and IDC ejector for correct cable locking. Compatible with all common pin counts from 3 to 25 for flexible use. Ideal for electronic components, power connectors, and PCB assemblies.
