Maxim Integrated Multiplexer 1 CMOS Quad SPST Logic IC 16-Pin TSSOP MAX4712EUE+
Specifications
| Country of Origin | India |
|---|---|
| Brand | Maxim Integrated |
| Height | 950μm |
| Length | 5.1mm |
| Model | MAX4712EUE+ |
| Width | 4.5mm |
| Mount Type | Surface |
| Output type | CMOS/TTL |
| Series | MAX4712 |
| Configuration | Quad SPST |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 16 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 11V |
| Logic Family | CMOS |
| Minimum Supply Voltage | -2.7V |
| Multiplexer/Demultiplexer | Multiplexer |
| Maximum On State Resistance | 30Ω |
Key Features
- The device supports rail-to-rail signal handling with fault-protected analog inputs capable of ±12V tolerance.
- It features a maximum on-state resistance of 30 ohms and a very low channel on-resistance match of 1 ohm.
- Operation supports single- and dual-supply voltage from -2.7V to 11V.
- The logic inputs are compatible with both CMOS and TTL families for versatile interfacing.
- Robust fault protection allows safe operation with supply faults and signal excursions beyond supply rails.
- Compact TSSOP package with a length of 5.1mm, width of 4.5mm, and height of 950 microns.
- Operating temperature range from -40°C to 85°C ensures reliable performance in harsh environments.
- Suitable for applications in avionics, communication systems, industrial and process control, battery-operated devices, and test equipment.
Product Description
The Maxim Integrated MAX4712EUE+ is a fault-protected analog multiplexer IC featuring a single CMOS quad single-pole single-throw (SPST) switch configuration. Packaged in a 16-pin TSSOP surface mount package, this device is designed for reliable signal routing and fault-tolerant operation in advanced electronic systems.
Operating voltage ranges from a minimum of -2.7V to a maximum of 11V with CMOS/TTL compatible logic inputs, the MAX4712EUE+ offers rail-to-rail signal handling and low on-resistance switching (maximum 30 ohms), ensuring minimal signal loss during operation. The close matching on resistance of 1 ohm between channels guarantees uniform performance across multiple switches.
Its fault protection capabilities provide tolerance to ±12V on analog inputs and various fault conditions including power-off states where all switches turn off to safeguard connected circuits. This makes it ideal for sensitive and safety-critical applications.
The device's compact TSSOP form factor (5.1mm length × 4.5mm width × 0.95mm height) and industrial operating temperature range (-40°C to 85°C) support deployment in rugged environments such as avionics, battery-powered systems, communication interfaces, data acquisition, and industrial process control.
Fault-protected analog inputs tolerate ±12V signals safely. Rail-to-rail signal handling provides full signal swing capability. Low on-state channel resistance (max 30 Ω) minimizes signal degradation. Compatible with both CMOS and TTL logic families for versatile use.
Single- and dual-supply operation with power-off switch disable feature. Compact 16-pin TSSOP surface mount package suitable for high-density PCB layouts. Wide temperature range (-40°C to 85°C) for industrial reliability.
Ideal for avionics, communications, industrial control, and test applications. Explore more advanced semiconductor ICs at EnvMart to support your industrial, laboratory, and commercial electronics projects with high-quality components.
Explore more products in our Multiplexer ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a voltage range of -2.7V to 11V.
The maximum on-state resistance is 30 ohms.
The TSSOP package has a length of 5.1mm, a width of 4.5mm, and a height of 950 microns.
The MAX4712EUE+ is compatible with both CMOS and TTL logic families.
It operates reliably within a temperature range of -40°C to 85°C.
This model features a 16-pin configuration.
It features a quad single-pole single-throw (SPST) switch configuration.
The device can tolerate fault conditions with analog inputs capable of ±12V signals.
The output type is CMOS/TTL compatible.
It is suitable for applications in avionics, communication systems, industrial control, and test equipment.
The very low channel on-resistance match of 1 ohm ensures uniform performance across multiple switches.
This model uses a surface mount type for installation.
