TDK-Lambda Isolated DC/DC Converter Through Hole 12V DC Output 1.3A 9-36V DC Input 15.6W 85°C Max Operating Temperature CCG15

TDK-Lambda CCG15 is an isolated DC/DC converter series offering a reliable 12V DC output at 1.3A current and 15.6W maximum output power. It is designed to operate over a wide input voltage range of 9V to 36V DC, supporting diverse power supply environments.

The device utilizes a through hole mounting type and a DIP package, encapsulated in a metal case with six-sided shielding to minimize electromagnetic noise and enhance mechanical robustness against shock and vibration. Its high efficiency of up to 88% ensures minimal power loss and improved thermal performance in applications.

Operating temperature spans from -40°C minimum up to a maximum of 85°C, making it suitable for harsh industrial conditions. The converter provides an isolation voltage of 500V DC, enhancing the safety and reliability of the power supply system. Its compact size with dimensions 25.4mm (L) x 9.9mm (W) x 9.9mm (D) and weight of approximately 20 grams facilitates space-efficient designs.

Output voltage adjustment up to 13.2V permits fine-tuning to application needs, while ripple and noise are tightly controlled at 95mV peak to peak, guaranteeing stable and clean output power for sensitive electronics.

The CCG15 Series fits diverse industrial and commercial use cases including test and measurement equipment, broadcast and communication systems, industrial automation, factory automation, and process control applications.

Wide DC input voltage range of 9 - 36V supports flexible power sources. Through-hole DIP packaging offers durable mounting and easy PCB integration. Six-sided metal shielding minimizes electromagnetic interference. High efficiency of 88% maximizes energy usage.

Operating temperature range from -40°C to +85°C suits extreme environments. 500V DC isolation voltage enhances safety and system robustness. Compact footprint of 1 inch x 1 inch supports space-saving designs. Complies with CE, EN 60950-1, UL/CSA 60950-1 safety standards.

This DC/DC converter series from TDK-Lambda represents a dependable and efficient power solution for demanding electronics in industrial, laboratory, communication, and automation sectors. Its robust design, efficient performance, and flexible input/output specifications make it ideal for integration into modern technical systems.
