Samtec IPL1 Series PCB Header, Right Angle, Through Hole, 16 Contacts, 2.54mm Pitch, 2 Row, Shrouded, 3.8A, 675V
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 675V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Designed with 16 individually shrouded contacts for secure wire-to-board connections.
- Features a dual-row configuration and 2.54 mm pitch for robust PCB layouts.
- Right angle orientation enhances compact board design and accessibility.
- Gold-plated phosphor bronze contacts ensure reliable electrical performance and corrosion resistance.
- Rated for up to 3.8A and 675V, suitable for medium-power signal and data applications.
- Housing is made from liquid crystal polymer rated for operating temperatures from -55°C to 125°C.
- Solder termination supports standard PCB assembly processes.
- Wire-to-board system suitable for industrial, instrumentation, and electronic equipment.
Product Description
The Samtec IPL1-108-01-S-D-RA-K PCB Header is a professional-grade, right angle through-hole connector engineered for precision wire-to-board connections. Providing 16 individually shrouded male contacts in a dual row arrangement, this header ensures secure connectivity in compact and high-density PCB applications.
With a standard 2.54 mm pitch and a robust shrouded construction, the IPL1-108-01-S-D-RA-K is optimized for use where mechanical protection and orientation accuracy are critical. Gold-plated phosphor bronze contact material guarantees high reliability, excellent signal integrity, and resistance against corrosion, making it suitable for both analog and digital signal transmission within demanding environments.
The housing is constructed from liquid crystal polymer, providing superior mechanical strength and thermal stability. The product is rated for continuous operation between -55°C and 125°C, making it apt for industrial and instrumentation devices exposed to wide temperature ranges. The header supports solder termination, ensuring compatibility with automated PCB assembly lines.
Electrical performance is ensured by a maximum current rating of 3.8A and a voltage rating of up to 675V. Right angle orientation is specifically selected to enhance board accessibility and packing density in enclosure designs.
Wire-to-board mounting adapts seamlessly to signal, control, and low-power distribution in electronic systems like measurement equipment, communication devices, and control panels. The shrouded feature provides orientation guidance and protection against accidental contact or misalignment.
This connector meets general industry standards for PCB headers, with no explicit regulatory approvals stated. Users can deploy it in custom PCBs across manufacturing, instrumentation, and commercial electronics.
Browse the full range of PCB Header connectors and related components in the Electronics & Electricals catalog for applications requiring dependable wire-to-board solutions. Explore Samtec’s high-performance connector series for demanding industrial and laboratory systems.
