Vishay 1-Element Uni-Directional TVS Diode 1.5 kW Surface Mount DO-214 Package SMCJ22A-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | SMCJ22A-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 35.5V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Uni-Directional |
| Minimum Breakdown Voltage Vbr | 24.4V |
| Maximum Reverse Stand-off Voltage Vwm | 22V |
| Peak Pulse Power Dissipation Pppm | 1.5kW |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 42.3A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Uni-directional configuration ensures protection against voltage transients in one direction.
- Peak pulse power dissipation rated at 1.5 kW for robust surge handling capability.
- Compact DO-214 package suitable for surface mounting on PCBs.
- Reliable clamping voltage of 35.5 V to protect sensitive electronics.
- Operating temperature range from -55°C to 150°C for versatile applications.
- Low maximum reverse leakage current of 1 μA to minimize power loss.
- Complies with automotive standard AEC-Q101 for enhanced quality assurance.
- ESD protection incorporated to safeguard against electrostatic discharge events.
Product Description
Vishay SMCJ22A-E3/57T is a 1-element uni-directional transient voltage suppressor (TVS) diode designed for surface mounting using the DO-214 package. It delivers a peak pulse power dissipation of 1.5 kW, making it suitable for effective transient voltage suppression in electronic circuits.
This TVS diode has a minimum breakdown voltage (Vbr) of 24.4 V and a maximum reverse stand-off voltage (Vwm) of 22 V, ensuring reliable protection against voltage spikes. The clamping voltage is rated at 35.5 V, limiting voltage surges to safe levels.
The device operates reliably in harsh temperature conditions, with a minimum operating temperature of -55°C and a maximum operating temperature up to 150°C. It also features a maximum peak pulse current (Ippm) of 42.3 A and a test current (It) of 1 mA, providing robust performance in transient conditions.
With a low maximum reverse leakage current of 1 μA, this diode minimizes power loss during normal operation. The diode configuration is single-element and uni-directional, optimized for transient voltage suppression only in one direction. Additionally, the product meets automotive standard AEC-Q101, making it suitable for automotive electronics applications.
The compact DO-214 package with dimensions approximately 7.11 mm length, 6.22 mm width, and 2.42 mm height supports efficient PCB mounting and space-saving design. The product includes ESD protection, safeguarding sensitive components from electrostatic discharge damage.
Uni-directional transient voltage suppression for protecting electronic devices. High surge power dissipation rating of 1.5 kW for energy absorption. Wide operating temperature range suitable for industrial and automotive environments.
Compact surface mount DO-214 package for space-efficient installation. Low leakage current improves energy efficiency and reliability. Automotive grade AEC-Q101 ensures suitability for automotive electronics. ESD protection improves device robustness and lifespan.
2-pin single diode element simplifies circuit design.
This TVS diode is ideal for protecting semiconductors and other sensitive components from transient surge voltages in industrial electronics, automotive, telecommunications, and power supply circuits. Its robust performance and automotive qualification make it a reliable choice for demanding applications.
Explore more products in the TVS Diodes category at EnvMart for comprehensive transient voltage suppression solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is rated at 1.5 kW, allowing it to handle robust surge conditions effectively.
The dimensions of the DO-214 package are approximately 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
The clamping voltage is rated at 35.5 V, which helps protect sensitive electronics from voltage surges.
This model features a single element configuration, designed specifically for uni-directional transient voltage suppression.
It complies with the automotive standard AEC-Q101, ensuring quality assurance for automotive applications.
The test current for this diode is 1 mA, which is used for its performance evaluation.
The maximum peak pulse current is rated at 42.3 A, providing robust performance during transient conditions.
The diode configuration is single and uni-directional, optimized for transient voltage suppression in one direction only.
