Samtec MECF Series Vertical Edge Connector Female, Surface Mount, 20 Contacts, 1 Row, Gold Plated, 280V MECF-20-01-L-DV-WT

Free Delivery in India | Lowest Global Shipping Charges

Samtec MECF Series Vertical Edge Connector Female, Surface Mount, 20 Contacts, 1 Row, Gold Plated, 280V MECF-20-01-L-DV-WT

Name: Samtec MECF Series Vertical Edge Connector Female, Surface Mount, 20 Contacts, 1 Row, Gold Plated, 280V MECF-20-01-L-DV-WT
Brand: Samtec
SKU: 422017
Price: 8.65 USD
Availability: InStock



Category Edge Connector Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	280V
Brand	Samtec
Orientation	Vertical
Current	3.5A
Model	MECF-20-01-L-DV-WT
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Beryllium Copper Alloy
Series	MECF
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Contact Plating	Gold
Number of Contacts	20
Contact Gender	Female
Connector Gender	Female
Card Type	Edge
Card Thickness	1.6mm

Key Features

This connector supports a current rating of 3.5A.
Contacts are gold plated to ensure durability and reliability.
The contact material is high-quality beryllium copper alloy.
Designed for cards with thickness of 1.6mm.
Operates within a temperature range of -55°C to 125°C.
Termination type is solder for secure attachment.
The housing is made of liquid crystal polymer for mechanical strength.
The connector system is part of the MECF series known for ruggedness.

Product Description

Samtec MECF-20-01-L-DV-WT is a vertical Edge Connector female, designed to provide reliable surface mount connection with precise alignment and robust mechanical properties. Featuring 20 contacts arranged in a single row, this connector efficiently supports a current rating of 3.5A and operates at a voltage of 280V, making it suitable for demanding electronic applications.

The contacts are plated with gold to provide excellent corrosion resistance and ensure long-term conductivity. Manufactured from beryllium copper alloy, the contacts offer mechanical resilience and reliable electrical performance. The connector is designed for edge cards with a thickness of 1.6mm, and the termination type is solder, which ensures a secure and stable installation on printed circuit boards.

Its housing is constructed from liquid crystal polymer, imparting high strength and endurance under thermal stress, capable of operating across a wide temperature range from -55°C to 125°C. This makes the MECF series ideal for use in various industries, including industrial manufacturing, laboratory equipment, electronic component assembly, and power distribution systems.

Being part of the MECF series, this connector supports rugged applications with an optional weld tab design and polarizing features in double row configurations up to 100 pins, although this model is a single row version for more specialized use cases.

This connector supports a current of 3.5A. Gold plating on contacts for enhanced durability. Beryllium copper alloy contacts provide strength and conductivity. Solder termination type for secure mounting. Liquid crystal polymer housing for high mechanical strength.

Wide operating temperature range from -55°C to 125°C. Voltage rating of 280V for versatile applications. Single row with 20 contacts for compact design. Designed for 1.6mm thick edge cards. Ideal for electronics manufacturing, industrial control systems, and power connectors.

Explore the extensive range of Samtec connectors and accessories on EnvMart for your industrial, electronic, and manufacturing needs.
