Samtec MEC8-VP Series Vertical Edge Connector Female Through Hole 10-Contacts 1 Row Solder

Free Delivery in India | Lowest Global Shipping Charges

Samtec MEC8-VP Series Vertical Edge Connector Female Through Hole 10-Contacts 1 Row Solder

Name: Samtec MEC8-VP Series Vertical Edge Connector Female Through Hole 10-Contacts 1 Row Solder
Brand: Samtec
SKU: 422013
Price: 6.86 USD
Availability: InStock



Category Edge Connector Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	185V
Brand	Samtec
Orientation	Vertical
Current	3.3A
Model	MEC8-VP
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	MEC8-VP
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Female
Connector Gender	Female
Card Type	Edge
Card Thickness	1.6mm

Key Features

The connector features a vertical orientation suitable for compact PCB designs.
It supports a maximum current rating of 3.3A, ideal for moderate power applications.
Contacts are plated with gold for enhanced conductivity and corrosion resistance.
Constructed with phosphor bronze contacts and a liquid crystal polymer housing for durability at operating temperatures from -55°C to 125°C.
Designed for edge card insertion with a card thickness of 1.6mm.
Termination is by soldering, providing secure and stable connections.
The connector is rated for a voltage of 185V, suitable for a wide range of electronic devices.
MEC8-VP series offers mini edge card connector solutions with double row options up to 80 pins.

Product Description

Samtec MEC8-110-02-L-VP vertical edge connector is a high-quality female connector featuring through hole mounting with 10 contacts arranged in a single row. It supports a current rating of 3.3A and operates reliably between -55°C and 125°C, making it suitable for industrial electronics and computing applications.

Its gold plated phosphor bronze contacts and liquid crystal polymer housing assure durability, corrosion resistance, and stable electrical performance under varying environmental conditions. The connector is designed for 1.6mm thick edge cards and terminates via soldering, ensuring secure connection on printed circuit boards.

This MEC8-VP series connector offers a vertical orientation which allows compact and efficient PCB layouts. Rated at 185V, it supports a wide voltage range for electronic components. The series includes press-fit and double row options for expanded pin counts, enhancing design flexibility.

The connector is widely used in industrial equipment, telecommunications, computing systems, and other manufacturing environments requiring robust edge connection solutions. The connector features a vertical orientation suitable for compact PCB designs.

It supports a maximum current rating of 3.3A, ideal for moderate power applications. Contacts are plated with gold for enhanced conductivity and corrosion resistance. Constructed with phosphor bronze contacts and a liquid crystal polymer housing for durability at operating temperatures from -55°C to 125°C.

Designed for edge card insertion with a card thickness of 1.6mm. Termination is by soldering, providing secure and stable connections. The connector is rated for a voltage of 185V, suitable for a wide range of electronic devices.

MEC8-VP series offers mini edge card connector solutions with double row options up to 80 pins. Ideal for industrial, electronics, and computing applications requiring reliable edge connection. Explore the Samtec MEC8-VP series and related Edge Connector products for your industrial electronics and PCB design needs on EnvMart.
