Samtec MEC1 Series Vertical Edge Connector Female, Surface Mount, 60 Contacts, 1 mm Pitch, 1 Row, Gold Plated MEC1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 2.2A |
| Model | MEC1 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | MEC1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Gold |
| Number of Contacts | 60 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | Edge |
| Card Thickness | 1.6mm |
| Insulator Material | black LCP |
Key Features
- Designed for vertical orientation with a single row layout.
- Operates safely with voltage up to 250V and current of 2.2A.
- Gold-plated phosphor bronze contacts provide excellent conductivity and corrosion resistance.
- Housing made of black liquid crystal polymer for durability and thermal stability.
- Suitable for operating temperatures between -55°C and 125°C.
- Termination type is solder, ensuring secure PCB connections.
- Card thickness compatibility is 1.6 mm for mini edge card applications.
- Lead-free solderable design supports environmental compliance.
Product Description
Samtec MEC1 Series Vertical Edge Connector MEC1 is a high-quality female Edge Connector designed for mini edge card sockets. Featuring 60 gold-plated phosphor bronze contacts arranged in a single row with a 1 mm pitch, this connector ensures reliable and efficient electrical connections in compact electronic assemblies. The vertical surface mount type allows easy integration on printed circuit boards, with lead-free solderability supporting environmentally friendly manufacturing processes.
The connector accommodates a card thickness of 1.6 mm and operates reliably across a wide temperature range from -55°C to 125°C. It is rated for a maximum voltage of 250V and a current of 2.2A, making it suitable for various electronic, industrial, and power connector applications.
The housing material is constructed from black liquid crystal polymer (LCP), offering excellent mechanical strength and thermal resistance. This series is ideal for demanding electronics components used in industrial, manufacturing, and commercial electronic equipment where compact edge card connections are necessary.
Vertical orientation with 60 contacts in one row. Gold contact plating over phosphor bronze contacts for durability and performance. Lead-free solder termination ensures environmental compliance. Supports mini edge card thickness of 1.6 mm.
Operating temperature range from -55°C to 125°C for reliability in harsh conditions. Voltage rating of 250V and current rating of 2.2A. Housing made from black liquid crystal polymer for strength and thermal stability. Ideal for electronics and industrial applications requiring mini edge card connectors.
Samtec MEC1 connectors provide a dependable solution for connecting edge cards in a wide variety of electronics manufacturing, industrial automation, and commercial electronic devices. Explore more connectors and electronic components at EnvMart to find complementary products and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this connector is 250V.
This connector features 60 contacts arranged in a single row.
The current rating for this model is 2.2A.
The contacts have a pitch size of 1 mm.
It uses a solder termination type for secure PCB connections.
This model is compatible with a card thickness of 1.6 mm.
The housing is made from black liquid crystal polymer, and the contacts are made from phosphor bronze with gold plating.
The operating temperature range is from -55°C to 125°C.
The connector is designed for vertical orientation.
Yes, it features a lead-free solderable design, supporting environmental compliance.
It is suitable for various electronic, industrial, and power connector applications.
The connector is manufactured in India.
