Samtec MEC1 Series Vertical Edge Connector Female Surface Mount, 30 Contacts, 1 mm Pitch, 1 Row, Solder Termination
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 2.2A |
| Model | MEC1 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | MEC1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Gold |
| Number of Contacts | 30 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | Edge |
| Card Thickness | 1.6mm |
| Insulator Material | black LCP |
Key Features
- Female connector with vertical orientation for edge card applications.
- 30 contacts at 1 mm pitch arranged in a single row.
- Gold-plated phosphor bronze contacts enhance conductivity and corrosion resistance.
- Liquid Crystal Polymer housing ensures durability at high temperatures.
- Designed to operate between -55°C and 125°C for industrial environments.
- Rated for 2.2 A current and 250 V voltage for reliable power handling.
- Solder termination type compatible with standard surface mount technology assembly.
- Compact 1.6 mm card thickness compatibility for mini edge card sockets.
Product Description
Samtec MEC1-130-02-F-D-A is a precision Vertical Edge Connector Female from the MEC1 series, designed for compact and reliable edge card interconnections in industrial and electronic assemblies. It features 30 gold-plated contacts on a 1 mm pitch arranged in a single row, providing efficient signal transmission and power handling with a current rating of 2.2 A and voltage rating of 250 V.
The connector's phosphor bronze contacts with gold plating ensure excellent electrical performance and durability against oxidation and wear. The housing is made of black Liquid Crystal Polymer (LCP), which offers high mechanical stability and can withstand temperatures ranging from -55°C to 125°C, making it suitable for harsh industrial, manufacturing, and electronics environments.
This component is surface mounted and uses solder termination to securely attach to PCBs, suitable for automated assembly lines. The card thickness supported is 1.6 mm, ideal for mini edge card socket applications. No specific standards approvals are listed, but construction and materials meet typical industrial usage requirements.
Female connector with vertical orientation for edge card applications. 30 contacts at 1 mm pitch arranged in a single row. Gold-plated phosphor bronze contacts enhance conductivity and corrosion resistance. Liquid Crystal Polymer housing ensures durability at high temperatures.
Designed to operate between -55°C and 125°C for industrial environments. Rated for 2.2 A current and 250 V voltage for reliable power handling. Solder termination type compatible with standard surface mount technology assembly.
Compact 1.6 mm card thickness compatibility for mini edge card sockets.
This MEC1 series edge connector is ideal for industrial, laboratory, electronics manufacturing, telecommunication, and computing equipment where reliable and durable PCB interconnections are critical. It supports efficient signal integrity and mechanical stability for demanding applications.
Explore more Edge Connectors and related components in the Electronics Components category at EnvMart for comprehensive sourcing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 2.2 A, ensuring reliable power handling for various applications.
The voltage rating is 250 V, making it suitable for standard electrical applications.
The contacts are made of phosphor bronze with gold plating, and the housing is constructed from Liquid Crystal Polymer (LCP).
It is designed to operate between -55°C and 125°C, suitable for harsh industrial environments.
This connector features 30 contacts arranged in a single row, providing efficient signal transmission.
The pitch of the contacts is 1 mm, which is standard for many edge card applications.
It uses a solder termination type, compatible with standard surface mount technology assembly.
It is compatible with a card thickness of 1.6 mm, ideal for mini edge card sockets.
The connector has a vertical orientation, specifically designed for edge card applications.
No specific standards approvals are listed, but the construction and materials meet typical industrial usage requirements.
The country of origin for this connector is India.
It is suitable for industrial, laboratory, electronics manufacturing, telecommunication, and computing equipment.
