Molex C-Grid III Series Right Angle Through Hole PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 Row, Shrouded 90136-2203
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Right angle locking header designed for use with locking housings.
- 3 contacts arranged in a single row with 2.54 mm pitch.
- Shrouded housing made of durable polyester material.
- Brass contacts plated with gold for reliable connectivity.
- Solder termination type suitable for through-hole mounting.
- Rated current of 3 amps and voltage of 350 volts.
- Operating temperature range from -55°C to 125°C.
- Tail pin length of 2.9 mm and mating pin length of 6.75 mm.
Product Description
Molex 90136-2203 is a C-Grid III Series right angle through hole PCB header featuring 3 contacts arranged in a single row with a 2.54 mm pitch, housed in a shrouded polyester casing. This connector is engineered for robust wire-to-board applications, providing a secure and reliable electrical connection in various electronic assemblies.
The header's brass contacts are plated with gold to enhance conductivity and prevent corrosion, ensuring long-term durability. It supports a maximum current of 3 amps and a voltage rating of 350 V, making it suitable for moderate power electronic circuits. The right angle orientation allows compact PCB designs and efficient use of board space.
Designed for through-hole mounting, the product uses solder termination to guarantee secure mechanical and electrical integrity. Its operating temperature ranges from -55°C to 125°C, allowing use in diverse environmental conditions including industrial and commercial electronics.
The shrouded housing offers protection against accidental contact and contamination, increasing safety and reliability. Tail pin length is 2.9 mm and mating pin length is 6.75 mm, providing proper engagement and mechanical stability during mating cycles.
Right angle locking header designed for use with locking housings. 3 contacts arranged in a single row with 2.54 mm pitch. Durable polyester housing with shrouded protection. Gold-plated brass contacts ensure reliable connectivity.
Through hole solder termination for secure mounting. Rated for 3 A current and 350 V voltage. Wide operating temperature range from -55°C to 125°C. Tail pin length of 2.9 mm and mating pin length of 6.75 mm.
This PCB header is ideal for industrial, commercial, manufacturing, and electronic assembly applications demanding reliable wire-to-board connections. Explore more in the PCB Headers category on EnvMart for additional connectors and components tailored to your technical needs.
