Molex C-Grid Series Straight Through Hole PCB Header, 50 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 70246-5004

The Molex 70246-5004 model is a C-Grid Series straight through hole PCB header designed for wire-to-board electrical connections. It features 50 male contacts arranged in 2 rows with a pitch of 2.54 mm, providing reliable and precise contact placement. The contacts are made from phosphor bronze and plated with gold, delivering superior conductivity and corrosion resistance suitable for demanding electronic environments.

The housing material is polybutylene terephthalate, renowned for its mechanical robustness and resistance to heat and chemicals. This header utilizes a shrouded design that protects the contacts and ensures correct connector mating, reducing the risk of misalignment or damage during assembly or operation.

Its through hole mount type allows for secure soldering to PCB boards, providing stable mechanical and electrical performance. The header supports an operating voltage of up to 250 V and a current rating of 2.5 A, making it apt for a variety of control and signal applications. It operates effectively within a temperature range from -55°C to 120°C, accommodating extreme environments commonly found in industrial and electronic manufacturing settings.

The tail pin and mating pin lengths of 3.43 mm and 2.54 mm respectively have been optimized for ease of assembly and durable connections. This combination makes the product well-suited for industrial automation systems, PCB assembly lines, and electronic component manufacturing where high reliability connectors are mandatory.

The Molex 70246-5004 PCB header complies with industry standards yet does not have specific certifications indicated. Its robust design and material choice make it a reliable solution for designers and manufacturers in the fields of electronics and electrical engineering.

Features 50 male contacts arranged in 2 rows for reliable connectivity. 2.54 mm pitch and row pitch ensure compatibility with standard PCB layouts. Gold-plated phosphor bronze contacts provide excellent corrosion resistance and conductivity.

Housing made of durable polybutylene terephthalate material for enhanced mechanical strength. Designed for through-hole mounting offering secure mechanical and electrical connection. Rated voltage of 250 V and current of 2.5 A for moderate power applications.

Operating temperature range from -55°C to 120°C suitable for varied environments. Shrouded design protects contacts and ensures proper mating with connectors. Tail pin length of 3.43 mm and mating pin length of 2.54 mm for precise soldering and connection.

Ideal for industrial, electronic assembly, automation, and PCB manufacturing applications. Explore more Molex connectors and related electronic components at EnvMart to meet your precise application needs.
