Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header, 10 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1021

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header, 10 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1021

Name: Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header, 10 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-1021
Brand: Molex
SKU: 206223
Price: 3.08 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	Mexico
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	5A
Mount Type	Through Hole
Housing Material	High Temperature Thermoplastic
Contact Material	Brass
Series	Micro-Fit 3.0
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	3mm
Contact Plating	Tin
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Mating Pin Length	3mm

Key Features

The housing features high temperature thermoplastic material for durability.
This shrouded connector has two rows and a right-angle orientation.
It supports a current rating of 5A with 250V operating voltage.
Contacts are made of brass with tin plating to ensure good conductivity.
Mount type is through hole with a solder termination type for secure fixing.
Operating temperature ranges from -40°C to 125°C for versatile application.
Positive latching design prevents accidental disconnection.
The product is manufactured in Mexico ensuring quality standards.

Product Description

Molex 43045-1021 Micro-Fit 3.0 Series Right Angle Through Hole PCB Header is a compact power connector designed for secure wire-to-board electrical connections. Featuring a 3 mm pitch with 10 male contacts arranged in two rows, this shrouded PCB header is engineered for reliability and durability in various industrial applications.

The housing is constructed from high temperature thermoplastic material, rated to withstand temperatures up to 265°C during IR reflow soldering, making it suitable for demanding manufacturing processes. The connector supports operation at currents up to 5A and voltages up to 250V, ensuring strong power distribution capability within a small footprint.

This PCB header's right angle orientation provides installation flexibility in tight PCB layouts, while metal press-fit retention clips secure the connector firmly to the board. Positive latching features on the housing lock connectors securely, preventing accidental disconnections, essential in high-vibration environments.

The brass contacts with tin plating offer reliable electrical performance with reduced arcing risks. With an operating temperature range from -40°C to 125°C, this connector is suited for use in a wide range of industrial, telecommunications, medical, consumer appliances, and data communication equipment.

High current carrying capacity in a miniature footprint optimizes space efficiency. High temperature housing material supports IR reflow soldering processes. Dual row, shrouded design enhances safety and performance. Right angle through hole mount delivers robust PCB connection.

Positive latching mechanism ensures secure mating connection. Fully isolated contacts reduce electrical interference and arcing. Suitable for military COTS, solar power, consumer appliances, telecommunications, and gaming terminals.

Manufactured in Mexico, guaranteeing quality and compliance.

This Molex Micro-Fit 3.0 Series PCB Header combines precision engineering with versatile usage across industrial, laboratory, manufacturing, and electronic assembly sectors. Discover more components in the Electronics & Electricals Connectors category at EnvMart.
