Samtec EHF Series Straight Surface PCB Header 40 Contacts 1.27 mm Pitch 2 Row Shrouded EHF-120-01-L-D-SM

Samtec EHF-120-01-L-D-SM is a high-quality straight surface mount PCB header designed for precise wire-to-board connections in electronic assemblies. This shrouded IDC header consists of 40 contacts arranged in two rows with a fine 1.27 mm pitch, suitable for compact and reliable circuit board interfacing.

The robust housing is made from liquid crystal polymer, providing excellent mechanical strength and electrical insulation. Contacts are fabricated from phosphor bronze and plated with gold, offering superior conductivity and corrosion resistance. The shrouded design includes polarizing notches and ejector latches to ensure accurate and secure mating with compatible connectors.

This header supports a current rating of 1.75A and is capable of operating within a wide temperature range from -55°C up to 125°C, making it ideal for demanding industrial and electronic applications. The male contact gender with a mating pin length of 3.05mm assures compatibility with industry-standard counterparts.

Termination is by solder to printed circuit boards, facilitating easy and reliable surface mount assembly. The two-row layout increases contact density, optimizing space on the PCB while maintaining accessibility.

The header features gold plated phosphor bronze contacts for reliable conductivity. Constructed with housing material of liquid crystal polymer for high durability. Supports a current rating of 1.75A suitable for low power electronic circuits.

Designed with polarizing notch and ejector latches for secure mating. Operates reliably between -55°C to 125°C ensuring versatile temperature range performance. Surface mount design allows integration on printed circuit boards with solder termination.

Male contact gender with a mating pin length of 3.05mm ensures compatibility with standard sockets. The 2-row configuration maximizes connection density without enlarging PCB footprint.

This product is widely used in industrial electronics, communication equipment, embedded systems, and other applications requiring robust, durable, and compact PCB connections. Its precision design and quality materials make it a reliable choice for new electronics development and replacement parts in manufacturing.
