Vishay 45 V 20 A Surface Mount Schottky Diode TO-263 3-Pin D2PAK MBRB2045CT-E3/45

Vishay MBRB2045CT-E3/45 is a surface mount Schottky diode designed for electronic and power applications requiring low forward voltage drop and fast switching capabilities.

The diode is housed in a durable TO-263 (D2PAK) package with 3 pins arranged in a common cathode configuration. It features a maximum continuous forward current of 20 A and can handle peak surge currents up to 150 A, making it suitable for high current applications.

Its maximum reverse voltage rating of 45 V and low forward voltage drop of 0.95 V contribute to efficient power rectification with reduced energy loss. The diode operates reliably over a wide temperature range from -65°C to 150°C, meeting rigorous automotive standard AEC-Q101.

This component is RoHS compliant, ensuring environmental safety and sustainability in electronic manufacturing. Its compact size (10.67 mm length, 9.65 mm width, and 4.83 mm height) facilitates use in space-constrained designs such as power supply circuits, voltage clamping, and reverse polarity protection.

Designed for fast switching and low power loss applications. Features a common cathode configuration with 3 pins. Maximum continuous forward current of 20 A with a peak surge current of 150 A. Low forward voltage drop of 0.95 V ensuring high efficiency.

Wide operating temperature range from -65°C to 150°C. Complies with RoHS standards and automotive AEC-Q101. Compact dimensions: 10.67 mm length, 9.65 mm width, and 4.83 mm height.

Widely used in industrial electronics, automotive, power converters, and rectification circuits, this Vishay Schottky diode is a reliable choice for enhancing performance while minimizing power dissipation.
