| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.5mm |
| Length | 3.5mm |
| Model | LS4150GS08 |
| Width | 1.7mm |
| Mount Type | Surface |
| Series | LS4150 |
| Maximum Operating Temperature | 175°C |
| Case | DO-204AL, molded epoxy over glass body |
| Package Type | Quadro Melf |
| Minimum Operating Temperature | -65°C |
| Polarity | Color band denotes cathode end |
| Terminals | Matte tin plated leads, solderable per |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 600mA |
| Peak Reverse Repetitive Voltage Vrrm | 50V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 100nA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 4ns |
Vishay LS4150GS08 is a high reliability 50 V, 600 mA switching diode designed for surface mount applications. The device utilizes a superectifier structure with a cavity-free glass-passivated junction which significantly reduces leakage current, making it suitable for efficient and reliable semiconductor circuits.
This diode comes in a DO-204AL molded epoxy package that provides excellent protection, including a UL 94 V-0 flammability rating. The compact 2-pin Quadro Melf package includes matte tin plated leads that are solderable per industry standards J-STD-002 and JESD 22-B102, ensuring robust mechanical and electrical connections.
Electrical characteristics include a maximum forward voltage of 1 V and peak reverse recovery time of 4 ns, providing fast switching speeds essential for high-frequency applications. It also supports a peak non-repetitive forward surge current of 4 A with an operating temperature range of -65°C to 175°C, granting wide industrial usability and reliability in harsh conditions.
Typical applications include high voltage rectification in CRT and television G2 grids, camera flash snubber circuits, and other fast switching requirements in consumer and industrial semiconductors. The diode's polarity is easily identified by a color band marking the cathode end.
Single diode with switching rectifier type in 2-pin Quadro Melf package. Maximum continuous forward current rated at 600 mA. Peak reverse repetitive voltage rated at 50 V. Operating temperature from -65°C to 175°C ensuring durability.
Compact size suitable for high density PCB assembly. Low leakage current and high forward surge capability. Complies with RoHS and commercial grade standards. Matte tin plated, solderable leads maintain secure placement.
This Vishay diode is an ideal choice for industrial, electronic component manufacturing, power management, and semiconductor device applications requiring robust and efficient switching diode solutions. Browse more products in the Schottky Diodes & Rectifiers category at EnvMart for compatible components.
