Vishay 3-Phase Bridge Rectifier 1600 V 500 A 5-Pin Through Hole Package D-63 VS-36MT160
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 10mm |
| Length | 28.5mm |
| Model | VS-36MT160 |
| Width | 28.5mm |
| Mount Type | Through Hole |
| Series | VS-36MT |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | D-63 |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 3 |
| Pin Count | 5 |
| Peak Reverse Repetitive Voltage Vrrm | 1600V |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 500A |
| Forward Current If | 35A |
| Peak Forward Voltage Vf | 1.19V |
| Universal, 3 way terminals | push-on, wrap around or solder |
| IXYS Bridge Rectifier Module, 1600 V 400 A, 5-Pin SingleBrand | IXYS |
| Vishay Bridge Rectifier, 1600 V 375 A, 5-Pin SingleBrand | Vishay |
Key Features
- Encapsulated compact design ensures excellent power to volume ratio.
- High thermal conductivity electrically insulated case supports operation up to 150°C.
- Offers peak forward voltage of 1.19 V and forward current rating of 35 A.
- Through hole mount type with 5-pin D-63 package enables easy installation.
- Suitable for industrial and instrumentation applications requiring full-wave rectification.
- Rated for minimum operating temperature of -55°C ensuring wide environmental tolerance.
- Nickel plated terminals are lead-free solderable for RoHS compliance.
Product Description
Vishay VS-36MT160 is a highly reliable three-phase bridge rectifier engineered for efficient full-wave rectification in electronic power applications. This device supports peak reverse repetitive voltage of 1600 V and surge forward current of up to 500 A, making it suitable for demanding industrial usage.
The rectifier features a compact encapsulated D-63 package with a through-hole mount style and five pins, providing excellent power density and ease of integration into power supply circuits. Its universal 3-way terminals allow installation via push-on, wrap-around, or solder methods to suit different assembly needs.
Operating temperature range from -55°C to 150°C extends the rectifier's usability in harsh environments. The package's high thermal conductivity coupled with an electrically insulated case aids thermal management, enhancing long-term reliability.
This bridge rectifier offers a forward current rating of 35 A with a low peak forward voltage of 1.19 V and a peak reverse current of 200 μA, balancing efficiency and performance. The nickel-plated terminals are solderable using lead-free Sn/Ag/Cu alloy, aligning with modern environmental standards.
Designed and qualified for industrial and consumer-level applications, the Vishay VS-36MT160 bridge rectifier is ideal for use in instrumentation, power conversion, motor drives, and other electronic equipment requiring robust rectification solutions.
Encapsulated 3-phase bridge rectifier supporting 1600 V peak reverse voltage. Universal mounting options with push-on, wrap around, or solder terminals. High thermal conductivity electrically insulated case for efficient heat dissipation.
Operating temperature range from -55°C to 150°C for versatile environmental conditions. Forward current of 35 A and peak surge current of 500 A for high load handling. Nickel plated lead-free solderable terminals ensuring RoHS compliance.
D-63 package with 5 pins facilitates through-hole mounting. Explore a wide range of Vishay semiconductor devices and Bridge Rectifiers on EnvMart for industrial and laboratory applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Vishay VS-36MT160 bridge rectifier has a peak reverse repetitive voltage rating of 1600 V.
This model can operate at a maximum temperature of 150°C.
The forward current rating of the VS-36MT160 is 35 A.
It can handle a peak non-repetitive forward surge current of up to 500 A.
The D-63 package has dimensions of 28.5 mm in length, 28.5 mm in width, and a height of 10 mm.
This unit features a through-hole mount type with a 5-pin configuration, allowing for easy installation.
The operating temperature range is from -55°C to 150°C, providing versatility in various environments.
It features universal 3-way terminals that can be installed using push-on, wrap-around, or solder methods.
The peak forward voltage of this model is 1.19 V.
The peak reverse current rating is 200 μA.
This bridge rectifier is suitable for industrial and instrumentation applications requiring full-wave rectification.
The country of origin for this bridge rectifier is India.
