Vishay Bridge Rectifier 1000 V 250 A 4-Pin Single Through Hole KBU6M-E4/51

Vishay KBU6M-E4/51 Bridge Rectifier is designed for reliable full-wave rectification in electronic circuits requiring up to 1000 V reverse voltage and 250 A surge current. The compact KBU package supports through-hole PCB mounting with 4 pins, facilitating secure solder connections and stable installation.

This bridge rectifier operates effectively across a wide temperature range from -50°C to 150°C, making it suitable for industrial and power electronics applications. The device offers low forward voltage drop of 1 V which enhances energy efficiency and reduces power loss during operation.

Featuring high surge current capacity of 250 A, it withstands transient process spikes without damage. Its isolating voltage of 1500 Vrms improves electrical safety by preventing unwanted current leakage through the package.

The robust physical dimensions - 23.7 mm length, 19.3 mm height, and 7.1 mm width - make it adaptable for various PCB layouts without sacrificing thermal dissipation.

This Vishay KBU6M series bridge rectifier is primarily used in industrial, manufacturing, HVAC, and power supply applications that require stable and efficient AC to DC conversion.

The rectifier supports a peak reverse repetitive voltage of 1000 V. Forward current rating of 6 A ensures steady current flow for moderate power applications. Peak surge current of 250 A guards against transient overloads.

Through-hole mount package with 4 pins enables easy integration into printed circuit boards. Operating temperature range from -50°C up to 150°C allows deployment in harsh environments. Low forward voltage of 1 V reduces conduction losses and heat generation.

Minimal peak reverse current of 5 μA keeps leakage currents low. Solder pins ensure secure mounting and electrical connection. Explore more Vishay Semiconductor Bridge Rectifiers and enhance your power electronics projects with reliable components available at EnvMart.
