Vishay Bridge Rectifier Three Phase Surface Mount D-63 Package 200 V 375 A 5-Pin VS-26MT20
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 10mm |
| Length | 28.5mm |
| Model | VS-26MT20 |
| Width | 28.5mm |
| Mount Type | Surface |
| Series | VS-26MT |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | D-63 |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 3 |
| Pin Count | 5 |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Peak Reverse Current Ir | 100μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 375A |
| Forward Current If | 25A |
| Peak Forward Voltage Vf | 1.26V |
| Universal, 3 way terminals | push-on (Fast-on), wrap around or solder |
Key Features
- Designed with 5 pins for single configuration bridge rectification.
- Rated peak reverse repetitive voltage of 200 volts for reliable operation.
- Capable of forward current of 25 amps and peak surge current of 375 amps.
- Operating temperature range from -55°C up to 150°C for wide environmental applications.
- Compact dimensions at 28.5mm length, 28.5mm width, and 10mm height to optimize space on PCB.
- Supplied with push-on (Fast-on), wrap around, or solder terminals for versatile mounting options.
- High thermal conductivity package providing excellent heat dissipation and power/volume ratio.
- Electrical insulation of case ensures safe mounting and operation.
Product Description
Vishay VS-26MT20 Bridge Rectifier is a rugged three-phase semiconductor device designed for efficient AC to DC conversion in power electronics and industrial applications. Featuring a surface mount D-63 package, it supports a peak reverse repetitive voltage of 200 V and a forward current rating of 25 A with a peak non-repetitive surge current of 375 A. The device's configuration includes five pins in a single bridge rectifier assembly optimized for industrial power systems.
This bridge rectifier is engineered with high thermal conductivity materials and an electrically insulated case, enabling safe chassis mounting through a center hole fixing. Its compact dimensions (28.5 mm x 28.5 mm x 10 mm) and push-on (Fast-on), wrap-around, or solder terminals ensure versatile installation in varied circuit layouts.
The device functions reliably across a broad temperature range from -55°C to 150°C, making it suitable for demanding industrial environments including three-phase power supplies, motor drives, UPS systems, and other HVAC and manufacturing applications requiring full-wave rectification with high current and voltage handling capacity.
Designed for three phase full-wave rectification with high efficiency. Robust thermal performance allows continuous operation at elevated temperatures. High surge current capability protects against transient load spikes.
Compact surface mount package reduces board space requirements. Low forward voltage drop minimizes power loss for energy-efficient operation. Push-on terminals facilitate quick and reliable connections. Electrical insulation enhances safety and prevents unintended shorts.
Wide temperature range supports use in harsh industrial environments. Suitable for power electronics, motor drives, and rectification systems. Engineered by Vishay, known for semiconductor reliability and performance.
Explore our category for advanced semiconductor components and Bridge Rectifiers tailored to your power conversion needs. Benefit from Vishay’s proven quality and extensive global support network on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak reverse repetitive voltage rating of this bridge rectifier is 200 volts.
This model can handle a maximum forward current of 25 amps.
The peak non-repetitive forward surge current rating is 375 amps.
The dimensions of the VS-26MT20 are 28.5 mm in length, 28.5 mm in width, and 10 mm in height.
The operating temperature range for this bridge rectifier is from -55°C to 150°C.
This model supports push-on (Fast-on), wrap-around, or solder terminals for versatile mounting options.
This bridge rectifier supports three phases for full-wave rectification.
The VS-26MT20 has a pin count of 5.
The package type of this bridge rectifier is D-63.
The forward voltage drop for this model is 1.26 volts.
The device is engineered with high thermal conductivity materials and features an electrically insulated case.
The VS-26MT20 is manufactured in India.
