STMicroelectronics Schottky Barrier Diode 150 V 1 A Surface Mount DO-214AC STPS1150A

Name: STMicroelectronics Schottky Barrier Diode 150 V 1 A Surface Mount DO-214AC STPS1150A
Brand: STMicroelectronics
SKU: 116466
Price: 20.22 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Diameter	2.71mm
Brand	STMicroelectronics
Height	2.03mm
Length	4.6mm
Model	STPS1150A
Width	2.95mm
Mount Type	Surface
Series	STPS1150
Maximum Operating Temperature	175°C
Package Type	DO-214AC
Minimum Operating Temperature	-65°C
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	150V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	1μA
Peak Non-Repetitive Forward Surge Current Ifsm	75A
Maximum Forward Voltage Vf	0.62V

Key Features

The diode offers up to 75 A peak surge current capacity.
Maximum forward voltage drop is 0.62 V for efficient power conversion.
Operates reliably within -65°C to 175°C temperature range.
Compact dimensions include 4.6 mm length, 2.95 mm width, and 2.03 mm height.
Features low peak reverse current of 1 μA for reduced leakage.
Package is a 2-pin DO-214AC suitable for surface mount applications.
No automotive standard compliance is specified.
Designed for applications in power management and rectification in electronic circuits.

Product Description

STMicroelectronics STPS1150A is a Schottky Barrier Diode with 150 V peak reverse voltage and 1 A maximum continuous forward current. Its surface mount DO-214AC package offers a compact footprint ideal for efficient PCB layouts in power and electronic equipment. This diode excels in applications requiring high efficiency and low forward voltage drop, minimizing power losses.

The device supports surge currents up to 75 A, enabling it to withstand transient conditions without damage. It operates reliably across a wide temperature range from -65°C to 175°C, suitable for demanding industrial and commercial electronics. The low peak reverse leakage current of 1 μA reduces unwanted power dissipation, making it ideal for power supplies, voltage clamping, and rectification tasks.

Physically, the diode measures 4.6 mm in length, 2.95 mm in width, and 2.03 mm in height, with a pin count of 2. This form factor supports automated surface mounting processes, enhancing production efficiency. Although it does not comply with any specific automotive standards, it is suitable for robust industrial and electronic applications.

The diode offers up to 75 A peak surge current capacity. Maximum forward voltage drop is 0.62 V for efficient power conversion. Operates reliably within -65°C to 175°C temperature range. Compact dimensions include 4.6 mm length, 2.95 mm width, and 2.03 mm height.

Features low peak reverse current of 1 μA for reduced leakage. Package is a 2-pin DO-214AC suitable for surface mount applications. No automotive standard compliance is specified. Designed for applications in power management and rectification in electronic circuits.

This Schottky diode is widely used in power supply circuits, switching power supplies, and industrial power controls, where its fast switching and low power loss enhance overall device efficiency and longevity. It supports various manufacturing processes, including automated insertion on reels to improve production throughput.
