| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 1.8mm |
| Model | NSR1020MW2T1G |
| Width | 1.35mm |
| Mount Type | Surface |
| Series | NSR1020MW2 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | Pb-Free, RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 40μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 5A |
| Maximum Forward Voltage Vf | 540mV |
onsemi NSR1020MW2T1G Schottky Barrier Diode is a high-performance semiconductor device designed for efficient low voltage rectification and fast switching applications. This diode features a Schottky barrier metal-semiconductor junction, resulting in a low forward voltage drop of 540 mV and minimal reverse leakage current, enabling improved energy efficiency and lower heat dissipation.
The diode is housed in a compact SOD-323 surface mount package with dimensions of 1.8 mm length, 1.35 mm width, and 1 mm height, making it well-suited for space-constrained electronic circuit designs. It supports a maximum continuous forward current of 1 A and can withstand peak reverse repetitive voltages up to 30 V, making it ideal for low voltage DC applications.
Rated for operation from -55°C to 125°C, the NSR1020MW2T1G delivers reliable performance under harsh thermal conditions. It features a peak non-repetitive forward surge current rating of 5 A, ensuring robustness in transient current scenarios.
The diode meets automotive industry standards with AEC-Q101 qualification and RoHS compliance, assuring quality and environmental safety. Its epoxy moulded case provides mechanical protection, while the lightweight package (approximately 11.7 mg) facilitates high-density PCB assembly in automotive, industrial, and consumer electronics applications.
Low forward voltage drop of 540 mV reduces power loss in circuits. Peak reverse current of only 40 μA ensures minimal leakage. Compact 2-pin SOD-323 package supports automated surface mount assembly. Wide operating temperature range from -55°C to 125°C.
Automotive grade with AEC-Q101 certification. Lightweight epoxy moulded construction. Suitable for high-frequency rectification and polarity protection. Optimized for low voltage, high frequency power conversion circuits.
Complies with RoHS environmental standards. Ideal for use in automotive, industrial, HVAC, and consumer electronic devices. Explore the range of semiconductors and Schottky diodes on EnvMart for industrial and commercial electronic applications.
Explore more products in our Schottky Diodes & Rectifiers category.
