KEMET PHE426 Film Capacitor, 22 nF, ±5 % Tolerance, 400 V DC, 160 V AC, Through Hole Mount PHE426

Free Delivery in India | Lowest Global Shipping Charges

KEMET PHE426 Film Capacitor, 22 nF, ±5 % Tolerance, 400 V DC, 160 V AC, Through Hole Mount PHE426

Name: KEMET PHE426 Film Capacitor, 22 nF, ±5 % Tolerance, 400 V DC, 160 V AC, Through Hole Mount PHE426
Brand: KEMET
SKU: 184253
Price: 0.35 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	Indonesia
Brand	KEMET
Height	9mm
Length	13mm
Model	PHE426
Packaging	Box
Width	4mm
Mount Type	Through Hole
Series	PHE426
Maximum Operating Temperature	105°C
Tolerance	±5 %
Capacitance	22nF
Minimum Operating Temperature	-55°C
Terminal type	Radial
Dissipation Factor	0.05%
Lead Length	5mm
Standards/Approvals	IEC 60384-16
Pin Count	2
Rated AC Voltage	160V ac
Rated DC Voltage	400V dc
Lead Pitch	10mm
Lead Diameter	0.6mm

Key Features

Rated for 400 V DC and 160 V AC operation.
Features a radial terminal type with 10 mm lead pitch.
Operates within a temperature range of -55°C to 105°C.
Encapsulated in self-extinguishing material meeting UL94V-0 standard.
Complies with IEC 60384-16 standard for film capacitors.
Ideal for pulse applications, snubber circuits, SMPS, TVs, monitors, and electrical ballasts.
Leads are 5 mm long with 0.6 mm diameter for secure connections.
Manufactured in Indonesia ensuring quality standards.

Product Description

KEMET PHE426 Film Capacitor is a high-quality passive electronic component designed for use in pulse and snubber circuits, switching mode power supplies (SMPS), TV monitors, electrical ballasts, and other high-frequency applications. This capacitor offers a capacitance of 22 nF with a precision tolerance of ±5 %, ensuring reliable performance in demanding electrical environments.

The capacitor is designed for through hole mounting with radial terminals and a 10 mm lead pitch, enabling straightforward PCB insertion and soldering. Its robust construction includes encapsulation in a self-extinguishing material compliant with UL94V-0, providing enhanced safety and durability. Rated for 400 V DC and 160 V AC, it operates efficiently within a temperature range of -55°C to 105°C, making it suitable for diverse industrial and commercial electronic applications.

The device complies with IEC 60384-16 standards, assuring consistent quality and trustworthy operation. Its dimensions include a length of 13 mm, width of 4 mm, and height of 9 mm, with lead diameters of 0.6 mm and lead lengths of 5 mm to support reliable mechanical and electrical connections. The low dissipation factor of 0.05% minimizes energy losses during operation.

Manufactured in Indonesia, the KEMET PHE426 Film Capacitor stands as a trusted solution for electronic designs requiring precise capacitance and high-voltage ratings. Its applications span industrial electronics, power conditioning, consumer electronics, HVAC controls, and laboratory instrumentation.

Rated for 400 V DC and 160 V AC operation. Through hole radial mount with 10 mm lead pitch. Wide operating temperature range of -55°C to 105°C. Encapsulated in UL94V-0 compliant self-extinguishing material. Complies with IEC 60384-16 standard.

Low dissipation factor of 0.05% for efficient performance. Dimensions: 13 mm length, 4 mm width, 9 mm height. Leads: 5 mm length, 0.6 mm diameter for secure fitting.

This capacitor is well suited for use in pulse circuits, snubber applications, and other high-frequency electronic systems in industrial, commercial, and laboratory settings. Browse our electronics components category on EnvMart to find this and related products from trusted brands like KEMET.
