KEMET 0.18 F Cylindrical Can Capacitor 40V dc Screw Mount Polar, 29.2A Ripple Current ALS71A184MF040
Specifications
| Country of Origin | Portugal |
|---|---|
| Voltage | 40V dc |
| Diameter | 66mm |
| Brand | KEMET |
| Height | 105mm |
| Length | 105mm |
| Model | ALS71A184MF040 |
| Mount Type | Screw |
| Construction | Cylindrical Can |
| Series | ALS71 |
| Termination Type | Screw |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±20 % |
| Lifetime | 38000 h |
| Capacitance | 0.18F |
| Minimum Operating Temperature | -40°C |
| Polarity | Polar |
| Leakage Current | 6mA |
| Standards/Approvals | IEC 60384-4, RoHS |
| Pin Count | 2 |
| Lead Pitch | 28.5mm |
| Equivalent Series Resistance ESR | 9mΩ |
| Capacitor Ripple Current | 29.2A |
Key Features
- Features a cylindrical can construction with screw termination.
- Operating voltage rating is 40 volts direct current.
- Capacitor polarity is polar and requires correct orientation.
- Capacitor ripple current rating is 29.2 amperes for high performance.
- Operating temperature range is from -40°C to 85°C ensuring durability.
- Lifetime expectancy is 38000 hours under specified conditions.
- Leakage current is low at 6 milliamperes for efficiency.
- Tolerance of capacitance is ±20% to accommodate variability.
Product Description
KEMET ALS71A184MF040 is a 0.18F capacitance aluminium electrolytic capacitor with a cylindrical can construction and screw mount type. It operates at 40V dc and is designed for applications requiring high ripple current and long life.
This capacitor features a polar design and a capacitor ripple current rating of 29.2A for reliable performance in demanding industrial and commercial environments. The capacitor is environmentally compliant with IEC 60384-4 and RoHS standards.
Its robust construction includes a cylindrical can with dimensions of 105mm length and height, and a diameter of 66mm. The capacitor is rated for operation between -40°C to 85°C and offers a long life of approximately 38000 hours.
Key technical specifications include a tolerance of ±20%, a leakage current of 6mA, and a low equivalent series resistance (ESR) of 9mΩ, ensuring stable and efficient operation. The capacitor features a two-pin screw termination with a lead pitch of 28.5mm to facilitate secure mounting.
The ALS71 series capacitors from KEMET are widely used in frequency converters, uninterruptible power supplies (UPS), and switch mode power supplies (SMPS) where high reliability and performance are mandatory.
Features a cylindrical can construction with screw termination. High ripple current capability of 29.2 amperes. Polar design requiring correct installation orientation. Operating temperature range from -40°C to 85°C. Long operational lifetime of 38000 hours under nominal conditions.
Compliance with IEC 60384-4 and RoHS for environmental standards. Dimensions: 105mm length and height, 66mm diameter. Low leakage current at 6mA. Tolerance of ±20% ensures capacitance accuracy. Equivalent series resistance (ESR) rated at 9mΩ.
This capacitor is manufactured in Portugal and is suitable for industrial, power electronics, HVAC, and manufacturing applications requiring reliable energy storage and filtering. Browse more capacitors and electronic components on EnvMart for additional specifications and options.
Explore more products in our Passive Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance value of this model is 0.18F.
It has a maximum operating voltage of 40V dc.
The ripple current rating is 29.2 amperes.
This capacitor operates within a temperature range of -40°C to 85°C.
The leakage current is low at 6 milliamperes.
It has a length and height of 105mm and a diameter of 66mm.
This model features a screw termination type with a lead pitch of 28.5mm.
It complies with IEC 60384-4 and RoHS environmental standards.
The equivalent series resistance (ESR) is rated at 9mΩ.
Yes, this capacitor is polar and requires correct orientation during installation.
This capacitor is manufactured in Portugal.
