Samtec TSM Series Vertical Surface Pin Header, 8 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-108-01-L-SV-P-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSM Series Vertical Surface Pin Header, 8 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-108-01-L-SV-P-TR

Name: Samtec TSM Series Vertical Surface Pin Header, 8 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-108-01-L-SV-P-TR
Brand: Samtec
SKU: 167143
Price: 1.82 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	475V
Brand	Samtec
Orientation	Vertical
Model	TSM-108-01-L-SV-P-TR
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold or Tin
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board

Key Features

The header features an unshrouded design for easy soldering and inspection.
It utilizes a black liquid crystal polymer housing for durability and heat resistance.
Contacts are made from phosphor bronze material plated with gold or tin for excellent conductivity.
Designed for vertical orientation to optimize PCB space and connection.
Operates reliably within a temperature range from -55°C to +125°C.
Suitable for 475V voltage rating, ensuring safe electrical performance.
Mount type is surface mount technology (SMT) for easy PCB assembly.
Termination type is solder, providing a secure electrical and mechanical connection.

Product Description

Samtec TSM-108-01-L-SV-P-TR is a vertical surface mount pin header designed for electronic board-to-board connections. Featuring 8 contacts in a single row with a 2.54 mm pitch, this unshrouded header employs a liquid crystal polymer housing that offers excellent mechanical strength and thermal stability, ideal for demanding industrial and commercial electronic applications.

The contacts, made from phosphor bronze and plated with gold or tin, ensure reliable conductivity and resistance to corrosion, making the product suitable for long-term use in various electronic assemblies. Its vertical orientation facilitates compact PCB layouts while maintaining optimal signal integrity.

Operating temperature ranges from -55°C to 125°C, supporting usage in harsh environments. Rated to handle voltages up to 475 VAC, this header meets the electrical performance needs of sophisticated electronic systems.

This SMT pin header features solder termination for robust and reliable mounting on printed circuit boards, enhancing assembly efficiency and durability in manufacturing. Its unshrouded design allows easy visual inspection and soldering access.

Commonly used across electronic manufacturing, telecommunications, computing hardware, and industrial control systems, the Samtec TSM series pin header is a versatile component that ensures dependable board-to-board connectivity.

The header features an unshrouded design for easy soldering and inspection. It utilizes a black liquid crystal polymer housing for durability and heat resistance. Contacts are made from phosphor bronze material plated with gold or tin for excellent conductivity.

Designed for vertical orientation to optimize PCB space and connection. Operates reliably within a temperature range from -55°C to +125°C. Suitable for 475V voltage rating, ensuring safe electrical performance. Mount type is surface mount technology (SMT) for easy PCB assembly.

Termination type is solder, providing a secure electrical and mechanical connection. Explore a wide range of PCB Headers and connectors on EnvMart to support your electronic design and manufacturing needs.
