TDK B32529 Film Capacitor 22 nF 63V AC 100V DC Through Hole 2 B32529C1223K000

The TDK B32529C1223K000 Film Capacitor is engineered for reliable performance in demanding electronic and automotive applications. With a capacitance value of 22 nF, it is optimized for precision filtering, coupling, blocking, bypassing, and RFI suppression tasks, ensuring circuit stability and effective noise mitigation.

This capacitor is rated for 63V AC and 100V DC, offering flexibility for modern electronic circuits and automotive subsystems. It features a through-hole mounting configuration, facilitating secure installation on printed circuit boards and providing mechanical stability in environments exposed to vibrations or temperature variations.

Constructed as part of the B32529 series, it adheres to the automotive AEC-Q200 Rev D standard, guaranteeing high reliability. The device also complies with RoHS and UL regulations, reflecting its suitability for environmentally conscious and safety-critical deployments.

Physical attributes include a compact form factor with a length of 7.3 mm, width of 2.5 mm, and height of 6.5 mm. The lead diameter is 0.5 mm, spaced at a 5 mm pitch, enabling easy integration in automated assembly processes and compatibility with standard PCB layouts.

Performance-enhancing features include high pulse strength and excellent contact reliability, making it appropriate for circuits that require robust energy handling and minimal signal losses. Its maximum operating temperature of 125°C allows usage in high-temperature industrial and automotive environments.

Use cases range across industrial automation, automotive electronics, PCB assemblies, power supplies, RF filtering, and noise suppression in sensitive electronic modules. The capacitor supports blocking and decoupling functions, serving both commercial and specialized design requirements.

22 nF capacitance ensures precision for signal processing and filtering. Designed for 63V AC and 100V DC applications for flexibility in circuit design. Automotive grade compliance (AEC-Q200 Rev D) for reliability in vehicle electronics.

RoHS and UL approved for eco and safety regulations. Through-hole mounting for robust PCB integration. Suitable for high pulse and harsh environmental requirements. Compact physical dimensions support dense circuit layouts.
