TDK Film Capacitor 100nF 160V AC 250V DC Through Hole High Pulse B32520C3104J000

The TDK B32520C3104J000 is a film capacitor designed for demanding electronic and automotive environments, offering a capacitance of 100nF with support for both 160V AC and 250V DC ratings. This device is part of the high-reliability B32520 series and is suitable for installation via through hole mounting, making it a robust choice for printed circuit board designs.

This capacitor is engineered for high pulse strength, delivering consistent performance even under fluctuating voltages, and is compliant with AEC-Q200 Rev D standards found in advanced automotive applications. With a maximum operational temperature of 125°C, it ensures reliability over a wide range of industrial conditions.

The compact construction includes a 10mm length, 8.5mm height, and 4mm width, allowing integration into space-constrained designs. A lead pitch of 7.5mm and lead diameter of 0.5mm facilitate secure PCB mounting and maintain electrical stability. The two-pin count further supports straightforward circuit configuration.

Manufactured with RoHS and UL approvals, this TDK film capacitor is environmentally friendly and adheres to strict industrial safety requirements. In addition to these features, the device is manufactured with high contact reliability, essential for long-term electrical performance.

Typical applications include blocking, coupling, decoupling, bypassing, and RFI suppression - especially relevant for automotive and industrial electronics that require noise immunity and voltage isolation.

Ideal for use in electronic equipment, instrument panels, vehicle electronics, industrial automation systems, and PCB assembly lines. The B32520C3104J000 capacitor’s reliability ensures stable operation in manufacturing, laboratory, commercial, and automotive sectors.
