KEMET 0.16 F Cylindrical Can Capacitor 63V DC Screw Terminal Polar ALS70A164NP063

Free Delivery in India | Lowest Global Shipping Charges

KEMET 0.16 F Cylindrical Can Capacitor 63V DC Screw Terminal Polar ALS70A164NP063

Name: KEMET 0.16 F Cylindrical Can Capacitor 63V DC Screw Terminal Polar ALS70A164NP063
Brand: KEMET
SKU: 146526



Category Capacitors Brand KEMET Condition New

Specifications

Country of Origin	Portugal
Voltage	63V dc
Diameter	77mm
Brand	KEMET
Height	146mm
Length	146mm
Model	ALS70A164NP063
Mount Type	Screw
Construction	Cylindrical Can
Series	ALS70
Termination Type	Screw
Maximum Operating Temperature	85°C
Tolerance	±20 %
Lifetime	40000 h
Capacitance	0.16F
Minimum Operating Temperature	-40°C
Polarity	Polar
Leakage Current	6mA
Standards/Approvals	RoHS, IEC 60384-4
Pin Count	2
Lead Pitch	31.8mm
Equivalent Series Resistance ESR	8mΩ
Capacitor Ripple Current	32.2A

Key Features

This capacitor features a cylindrical can construction for durability.
It has a capacitance of 0.16 farads suitable for high-capacity applications.
Rated for a maximum voltage of 63 volts DC, ensuring reliable performance.
Screw termination and mounting make installation secure and straightforward.
Designed with a polar type polarity and two pins for connectivity.
Features an equivalent series resistance (ESR) of 8 milliohms to minimize losses.
Capacitor ripple current rating of 32.2 amperes supports high current demands.
Operating temperature range from -40°C to 85°C allows use in harsh environments.

Product Description

KEMET ALS70A164NP063 is a high-capacitance 0.16 F cylindrical can capacitor rated for 63V DC with screw terminal mounting and polar polarity. It delivers exceptional performance and reliability in industrial and commercial electronics applications.

This capacitor offers 0.16 Farads capacitance and is designed in a polar cylindrical can form, measuring 146 mm in height and length with a 77 mm diameter. The screw termination provides secure connections.

The device supports a ripple current of 32.2 A and has a low equivalent series resistance (ESR) of 8 mΩ, enhancing efficiency in power electronics circuits. It operates reliably between -40°C to 85°C and boasts a long service life rated at 40,000 hours.

The ALS70 series capacitors are RoHS compliant and meet IEC 60384-4 international standards. These capacitors are ideally suited for frequency converters, uninterruptible power supplies (UPS), switch mode power supplies (SMPS), and other demanding industrial applications requiring durability and high reliability.

This capacitor features a cylindrical can construction for durability. It has a capacitance of 0.16 farads suitable for high-capacity applications. Rated for a maximum voltage of 63 volts DC, ensuring reliable performance.

Screw termination and mounting make installation secure and straightforward. Designed with a polar type polarity and two pins for connectivity. Features an equivalent series resistance (ESR) of 8 milliohms to minimize losses.

Capacitor ripple current rating of 32.2 amperes supports high current demands. Operating temperature range from -40°C to 85°C allows use in harsh environments. Long lifetime of 40,000 hours provides durability for industrial applications.

Complies with RoHS and IEC 60384-4 standards for safety and quality. This product supports demanding applications in industrial, commercial, and manufacturing sectors, including power electronics and energy management systems.
