onsemi 1 kV 1 A Switching Diode 2-Pin DO-214AC S1M

Free Delivery in India | Lowest Global Shipping Charges

onsemi 1 kV 1 A Switching Diode 2-Pin DO-214AC S1M

Name: onsemi 1 kV 1 A Switching Diode 2-Pin DO-214AC S1M
Brand: onsemi
SKU: 207416
Price: 0.16 USD
Availability: InStock



Category Semiconductor Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	2.2mm
Length	4.75mm
Model	S1M
Width	2.95mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	1kV
Diode Configuration	Single
Rectifier Type	Switching
Peak Reverse Current Ir	1μA
Peak Non-Repetitive Forward Surge Current Ifsm	30A
Maximum Forward Voltage Vf	1.1V
Peak Reverse Recovery Time trr	1.8μs
Vishay 1 kV 1 A Diode General Purpose 2-Pin DO-214AC S1M-E3/5ATBrand	Vishay

Key Features

Surface mount with DO-214AC package type.
Maximum forward voltage of 1.1 V ensuring efficient diode operation.
Peak non-repetitive forward surge current rated at 30 A.
Operating temperature range from -55°C to 150°C for industrial applications.
Peak reverse recovery time of 1.8 microseconds for fast switching.
Low peak reverse current of 1 microampere minimizes leakage current.
RoHS compliant, ensuring environmental safety.

Product Description

onsemi S1M Switching Diode in a 2-pin DO-214AC package offers a maximum continuous forward current of 1 A and a peak reverse repetitive voltage of 1 kV. Its single diode configuration is optimized for switching applications in various electronic circuits.

The diode features a maximum forward voltage of 1.1 V and a very low peak reverse current of 1 µA, ensuring minimal power loss and high efficiency. It sustains a peak non-repetitive forward surge current of up to 30 A, making it suitable for transient conditions in electrical systems.

Designed for surface mount applications, the S1M diode's compact form factor with dimensions of 4.75 mm length, 2.95 mm width, and 2.2 mm height allows integration into high-density circuit boards. It operates reliably over a temperature range from -55°C to 150°C, catering to demanding industrial, electronic, and power applications.

The diode also features a peak reverse recovery time of 1.8 microseconds, facilitating fast switching necessary in power management and signal processing. Compliance with RoHS standards indicates conformity with environmental regulations for safe usage.

Surface mount DO-214AC package for versatile circuit design. Maximum continuous forward current of 1 A suitable for moderate load applications. Peak reverse voltage rating of 1 kV supports high voltage tolerance. Very low leakage current and quick recovery time enhance efficiency.

Supports industrial temperature range for rugged environments. Compliant with RoHS environmental safety standards.

This onsemi S1M diode is ideal for use in industrial electronics, power supplies, switching circuits, and general-purpose applications requiring reliable switching performance and voltage tolerance.
