DiodesZetex General Purpose 100 V 10 A Surface Mount TO-252 3-Pin Schottky Diode SBR10100CTL-13

DiodesZetex SBR10100CTL-13 is a high-performance general purpose Schottky barrier diode designed for surface mount applications. Featuring a compact TO-252 (DPAK) 3-pin package, it supports a continuous forward current of 10 A and a peak reverse repetitive voltage of 100 V, making it suitable for a wide range of electronic circuits requiring efficient rectification and low forward voltage drop.

Its low forward voltage of 840 mV minimizes conduction losses and improves power efficiency in power supply and conversion systems. The diode's operating temperature range from -65°C to 175°C enables operation in demanding industrial and automotive environments. The common cathode configuration is ideal for applications in power management, switching power supplies, and motor controls.

The 110 A peak non-repetitive forward surge current rating ensures reliable handling of transient currents. Compliance with automotive AEC standards and manufacturing under FBI standards guarantees high reliability and consistent quality. This diode is RoHS compliant, supporting eco-friendly designs and regulatory requirements.

The small surface mount package offers easy PCB assembly and compact layouts for industrial electronics, automotive controls, instrumentation, and manufacturing equipment. Its robust performance characteristics make it valuable in HVAC systems, industrial automation, and consumer electronics.

Maximum continuous forward current of 10 A ensures reliable performance. Peak reverse repetitive voltage of 100 V offers high voltage tolerance. Low forward voltage drop of 840 mV reduces power losses. Operating temperature range from -65°C to 175°C for varied environments.

Compact surface mount TO-252 (DPAK) package for space-saving PCB design. Common cathode diode configuration suitable for multiple rectifier applications. Peak non-repetitive forward surge current capacity of 110 A for transient tolerance.

Automotive standard compliant (AEC) ensuring high quality and reliability. Manufactured to FBI standards and RoHS compliant for environmental safety.

This Schottky diode by DiodesZetex is an ideal choice for power rectification in industrial, automotive, electronic component manufacturing, and semiconductor circuit design. Explore more diode products and semiconductor components in the EnvMart catalog for your application needs.
