Taiwan Semiconductor 50 V 1 A Surface Mount Switching Diode DO-214AC US1A R3

Free Delivery in India | Lowest Global Shipping Charges

Taiwan Semiconductor 50 V 1 A Surface Mount Switching Diode DO-214AC US1A R3

Name: Taiwan Semiconductor 50 V 1 A Surface Mount Switching Diode DO-214AC US1A R3
Brand: Taiwan Semiconductor
SKU: 392921
Price: 0.23 USD
Availability: InStock



Category Semiconductor Diodes Brand Taiwan Semiconductor Condition New

Specifications

Country of Origin	India
Brand	Taiwan Semiconductor
Height	2.3mm
Length	4.6mm
Model	US1A R3
Width	2.83mm
Mount Type	Surface
Series	US1X
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-55°C
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	50V
Diode Configuration	Single
Rectifier Type	Switching
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	30A
Maximum Forward Voltage Vf	1V
Peak Reverse Recovery Time trr	50ns

Key Features

This diode features a single configuration suitable for switching applications.
It has a maximum forward voltage drop of 1 V and a peak non-repetitive forward surge current of 30 A.
The diode operates reliably within a temperature range of -55°C to 150°C.
Compact dimensions of 4.6 mm length, 2.83 mm width, and 2.3 mm height enable surface mount applications.
Peak reverse recovery time is 50 ns, supporting fast switching performance.
Low peak reverse current of 5 μA enhances efficiency in power electronic circuits.
It is packaged in a 2-pin DO-214AC form factor with surface mount mount type.

Product Description

Taiwan Semiconductor US1A R3 is a surface mount switching diode designed for semiconductor applications requiring a maximum continuous forward current of 1 A with a peak reverse repetitive voltage rating of 50 V. This model is supplied in a DO-214AC package and features a single diode configuration optimized for switching tasks.

The diode exhibits a maximum forward voltage of approximately 1 V and can tolerate peak non-repetitive forward surge currents up to 30 A, making it suitable for robust electronic circuits. Its operation within a wide temperature range from -55°C to 150°C ensures reliability in various industrial and commercial environments.

Its fast peak reverse recovery time of 50 ns facilitates efficient switching in power management and semiconductor devices, minimizing power losses. The package dimensions - 4.6 mm length, 2.83 mm width, and 2.3 mm height - support easy integration into compact surface mount circuit boards.

This diode is ideal for use in industrial automation, power electronics, and semiconductor circuit designs. Design features include a low peak reverse current of 5 μA which contributes to energy efficiency in electronic products.

Supplied with 2 pins for surface mount installation, this device supports high production efficiency and assembly automation. Its rugged design suits applications in commercial electronics, HVAC controls, and manufacturing equipment.

Package type DO-214AC ensures compatibility with standard surface mount assembly processes. Temperature tolerance from -55°C to 150°C enables operation in harsh and variable environments. The diode’s switching type and features meet demand for rapid electronic switching requirements.

This Taiwan Semiconductor US1A R3 diode is a dependable solution for professionals seeking quality and efficient semiconductor switching components in industrial, commercial, and laboratory environments. Explore more semiconductor and diode products on EnvMart to suit all technical requirements.

Explore more products in our Semiconductor Diodes category.
