DiodesZetex PNP Bipolar Transistor 1 A, 30 V, 4-Pin SOT-223 Package FZT549TA

DiodesZetex FZT549TA is a general-purpose PNP bipolar transistor designed for both amplification and switching applications in industrial, automotive, and electronic circuits. It offers a maximum DC collector current of 1 ampere and a maximum collector emitter voltage of 30 volts, making it well-suited for medium power electronics applications.

The transistor features a 4-pin SOT-223 surface mount package that allows for efficient heat dissipation and compact board layouts. The maximum power dissipation rating is 2 watts, enabling it to handle moderate power loads reliably under continuous operation.

Its minimum DC current gain (hFE) of 30 supports sufficient amplification, and the high transition frequency of 100 MHz makes it suitable for high-speed switching circuits. The device operates safely within -55°C to 150°C, making it ideal for industrial environments that require wide temperature tolerance.

Compliance with the automotive standard AEC-Q101 further qualifies the FZT549TA for use in automotive electronics, including sensor circuits, signal switches, and power management modules.

Key mechanical dimensions include a 6.55 mm length, 7.1 mm width, and 1.65 mm height, supporting compact PCB designs. This transistor is manufactured in Germany, assuring consistent quality and reliability for demanding applications.

General purpose PNP bipolar transistor for amplification and switching. 1 A max collector current with 30 V max collector emitter voltage. SOT-223 4-pin surface mount package for efficient mounting and cooling. 2 W maximum power dissipation for robust operation.

Minimum current gain of 30 suitable for a variety of circuit requirements. Operating temperature from -55°C to 150°C for industrial use. High transition frequency of 100 MHz for fast switching applications. AEC-Q101 automotive compliance ensures reliable automotive use.

This transistor is a versatile component for electronic device manufacturers, industrial control systems, automotive electronics, and power management circuits. Browse EnvMart’s Semiconductor catalog for more Bipolar Transistors and components from DiodesZetex and other leading brands.
