DiodesZetex 1 2-Input XOR Logic Gate, 5-Pin SOT-353, CMOS Input, 1.65 to 5.5 V Operating Range, 74LVC1G86SE-7

DiodesZetex 74LVC1G86SE-7 1 2-Input XOR Logic Gate is a low-voltage CMOS device packaged in a compact 5-pin SOT-353 surface mount package. This single gate device offers XOR logic function with high performance and low power consumption, suitable for modern electronic designs.

Operating within a supply voltage range of 1.65 to 5.5 V, it ensures compatibility with LVTTL and TTL input levels along with LVCMOS output levels. The maximum propagation delay of 5.5 ns supports high-speed digital logic circuits, allowing precise timing control in complex systems.

Designed for industrial temperature ranges from -40°C up to 125°C, this logic gate can be reliably used in harsh environments typical in automotive and industrial applications, although it does not hold automotive standard certification.

The push-pull output stage can source and sink up to 32 mA, providing adequate drive capability for logic-level loads. The compact package dimensions of 2.2 mm by 1 mm allow dense PCB layouts benefiting space-constrained designs.

This device is suitable for industrial electronics, computing, communication equipment, and embedded control systems requiring high-speed logical operations with low power dissipation. The surface mount design aids automated assembly processes for manufacturing efficiency.

This logic gate provides XOR functionality with a single element per package. Operates over a voltage range of 1.65 V to 5.5 V compatible with LVTTL/TTL inputs and LVCMOS outputs. Maximum propagation delay of 5.5 nanoseconds allows high-speed switching.

Designed for operation between -40°C and 125°C for industrial temperature ranges. Push-pull output type supports output currents of ±32mA ensuring reliable drive capability. Compact 2.2 mm length and 1 mm height package minimizes PCB footprint.

The device is RoHS compliant and intended for surface mount technology (SMT) assembly.

Choose DiodesZetex products for reliable semiconductor components trusted in electronics manufacturing. Browse the Logic Gates category on EnvMart to find this and related devices for your design needs.
