DiodesZetex 1 2-Input AND Logic Gate, 5-Pin SOT-25, CMOS, 1.65 to 5.5 V Operating Voltage, 5.5 ns Propagation 74LVC1G08W5-7

DiodesZetex 74LVC1G08W5-7 is a single 2-input AND logic gate IC packaged in a compact 5-pin SOT-25 surface mount casing. It operates with a low-voltage CMOS technology compatible with an operating voltage range from 1.65 to 5.5 V, making it suitable for modern electronic circuit requirements where power efficiency and speed are essential.

This device offers fast switching speeds with a maximum propagation delay of 5.5 ns at a given load capacitance, ensuring quick logical processing in digital systems. The single gate per package design allows for space-saving PCB layouts without compromising performance.

The inputs use CMOS technology for noise immunity and low static power consumption, compatible with LVTTL/TTL input types, while the push-pull output stage delivers robust driver capabilities with a maximum output current of ±32 mA. The logic family classification is LVC (Low-Voltage CMOS), supporting versatile digital logic applications.

Operational temperature ranges from -40°C to 125°C make it suitable for industrial and commercial temperature environments. The SOT-25 package dimensions of 3.1 mm length and 1.3 mm height facilitate easy surface mounting and integration into compact electronic devices.

in China, this part adheres to RoHS compliance standards, ensuring environmental and safety regulatory conformity. It does not carry specific automotive certifications, targeting general electronics applications including industrial equipment, consumer electronics, and embedded systems.

Single 2-input AND logic gate per package in SOT-25 surface mount package. Operating voltage range of 1.65 to 5.5 V suitable for low-voltage digital systems. Fast propagation delay of 5.5 ns delivering high-speed logic switching.

Inputs compatible with LVTTL and TTL logic levels, output stage provides push-pull drive. Wide operating temperature range from -40°C to 125°C for diverse environments. Compact dimensions of 3.1 mm by 1.3 mm for efficient PCB space usage.

RoHS compliant and manufactured in China. This product is excellent for industrial, commercial, and consumer electronic circuit designs requiring a reliable low-voltage AND Logic Gate IC. Explore more semiconductor logic ICs and components on EnvMart to find complementary products for your designs and projects.
