Molex C-Grid III Series Straight Through Hole PCB Header, 5 Contact(s), 2.54 mm Pitch, 1 Row, Shrouded 90136-1205

Molex 90136-1205 C-Grid III Series is a reliable straight through hole PCB header designed for wire-to-board connector applications. Featuring 5 gold-plated brass contacts spaced at a 2.54 mm pitch in a single row, this shrouded header ensures stable and secure connections suitable for a wide range of electronic devices. Its polyester housing provides mechanical strength and insulation.

Designed for through hole mounting with solder termination, it supports an operating current of 3A and voltage up to 350V. The product performs reliably in a broad temperature range from -55°C to 125°C, making it suitable for industrial and laboratory environments where durability and performance are critical.

The tail pin length measures 2.9 mm while the mating pin length is 6.75 mm, matching the Molex C-Grid III locking housings for a secure fit. The straight orientation and shrouded design help prevent misalignment and protect the contacts during installation and operation.

This PCB header is extensively used in manufacturing and repairing PCBs for industrial machinery, power connectors, instrumentation, and automation equipment. This PCB header features a shrouded, straight orientation for secure mating.

It has 5 gold-plated brass contacts suitable for reliable conductivity. The housing is made of durable polyester material. Rated to carry a current of 3A and voltage of 350V. Designed for through hole mounting with solder termination.

Operates within temperature range -55°C to 125°C. The tail pin length is 2.9 mm and mating pin length is 6.75 mm for optimal connection. Ideal for electronics manufacturing in industrial, laboratory, and commercial PCB assembly applications.
