DiodesZetex 600 V 3 A General Purpose Rectifier Diode Surface Mount DO-214AB S3J-13-F

DiodesZetex S3J-13-F is a general purpose, single rectifier diode designed for reliable performance in power electronics applications. It is housed in a surface mount DO-214AB (SMC) package, making it suitable for automated assembly and efficient PCB design. Rated for a maximum continuous forward current of 3 amperes and a peak reverse repetitive voltage of 600 volts, it ensures dependable rectification for a broad range of industrial and electronic uses.

This diode features a low maximum forward voltage drop of 1.15 volts, improving efficiency in circuits. With a peak non-repetitive forward surge current of 100 amperes, it can handle transient load conditions effectively. Its operating temperature range from -65°C to 150°C provides robustness under harsh environments.

The compact form factor with dimensions of 7.11 mm length, 6.22 mm width, and 2.3 mm height facilitates integration into dense assemblies. Its 2-pin configuration and surface mount design enable ease of use in high-volume manufacturing processes.

The diode exhibits a low peak reverse current of 250 microamps, reducing leakage and power loss. The product complies with FBI standards for quality and performance assurance. It is ideal for general purpose rectification tasks in industrial, consumer electronics, automotive electronics, and power supply devices.

This diode features a maximum continuous forward current of 3 amperes. It offers a peak reverse repetitive voltage of 600 volts. The diode has a maximum forward voltage drop of 1.15 volts. Its peak non-repetitive forward surge current is 100 amperes.

The operating temperature range extends from -65°C to 150°C. The compact DO-214AB (SMC) package measures 7.11 mm length, 6.22 mm width, and 2.3 mm height. It has a low peak reverse current of 250 microamps. The diode features a single diode configuration with 2 pins.

Suitable for surface mounting on PCBs in power electronics designs. Complies with FBI standards and is designed for reliable general purpose rectification.

This DiodesZetex diode is widely used across industrial, electronic manufacturing, automotive, and laboratory environments where robust rectification capability is required. It supports efficient power management in switching power supplies, converters, and rectifier circuits.
