Vishay General Purpose 400 V 1.5 A Diode 2-Pin Surface Mount DO-214AA RS2G-E3/52T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.44mm |
| Length | 4.57mm |
| Model | RS2G-E3/52T |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | RS2G |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1.5A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 150ns |
Key Features
- Capable of maximum continuous forward current of 1.5 A.
- Peak reverse repetitive voltage rating of 400 V ensures high voltage tolerance.
- Surface mount DO-214AA package for easy PCB assembly.
- Fast recovery time of 150 ns suitable for efficient switching applications.
- Operating temperature range from -55°C to 150°C for robust performance.
- Low maximum forward voltage of 1.3 V improves power efficiency.
- Peak non-repetitive forward surge current of 50 A for transient tolerance.
- Meets automotive standard AEC-Q101 for reliable automotive use.
Product Description
Vishay RS2G-E3/52T is a general purpose switching diode designed for surface mount applications in the compact DO-214AA package. Rated for a peak reverse repetitive voltage of 400 V and a maximum continuous forward current of 1.5 A, it is ideal for use in power rectification and fast switching circuits. The diode features a fast recovery time of 150 ns, making it suitable for efficient and reliable switching operations in industrial, automotive, and electronics manufacturing contexts.
This diode operates efficiently over a wide temperature range from -55°C to 150°C, ensuring stable performance in harsh environments. It supports a peak non-repetitive forward surge current of 50 A to withstand transient spikes. The maximum forward voltage drop of 1.3 V contributes to lower power dissipation in circuits where energy efficiency is critical.
The DO-214AA package guarantees an optimized footprint for surface mount technology (SMT) on printed circuit boards, facilitating automated assembly and enhanced thermal management. The product meets the automotive AEC-Q101 standard, certifying its reliability and quality for automotive electronic systems.
Maximum continuous forward current: 1.5 A. Peak reverse repetitive voltage: 400 V. Fast reverse recovery time: 150 ns. Operating temperature range: -55°C to 150°C. Low forward voltage drop of 1.3 V. Peak non-repetitive surge current: 50 A.
Compact surface mount DO-214AA package. Automotive standard AEC-Q101 compliant. Dimensions: Length 4.57 mm, Width 3.94 mm, Height 2.44 mm.
This diode is widely used in industrial power supplies, automotive electronics, telecommunication devices, and consumer electronics requiring efficient and reliable fast recovery rectifiers. Its versatile specifications make it an essential component for switching and protection functions in various electrical circuits.
Explore our extensive range of semiconductors and electronic components at EnvMart for professional industrial and manufacturing applications.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 1.5 A.
This model has a peak reverse repetitive voltage rating of 400 V.
It features a fast recovery time of 150 ns, making it suitable for efficient switching applications.
The operating temperature range is from -55°C to 150°C, ensuring stable performance in harsh environments.
This diode comes in a compact DO-214AA package, optimized for surface mount technology.
The maximum forward voltage drop is 1.3 V, which helps improve power efficiency.
It supports a peak non-repetitive forward surge current of 50 A, allowing it to withstand transient spikes.
This model meets the automotive standard AEC-Q101, certifying its reliability for automotive applications.
The dimensions of this diode are 4.57 mm in length, 3.94 mm in width, and 2.44 mm in height.
It is classified as a general purpose rectifier, suitable for various applications.
The peak reverse current is rated at 200 μA.
This diode is widely used in industrial power supplies, automotive electronics, telecommunication devices, and consumer electronics.
