onsemi Bipolar Transistor 600 mA NPN 40 V 4-Pin SOT-223 PZT2222AT1G

onsemi PZT2222AT1G Bipolar Transistor is a reliable general purpose NPN semiconductor device designed for robust electronic switching and amplification in industrial and commercial electronics.

This transistor supports a maximum DC collector current of 600 mA and can withstand a collector-emitter voltage of 40 V, making it suitable for low to medium power electronic circuits. Packaged in a compact 4-pin SOT-223 surface-mount package, it allows efficient PCB layout and thermal dissipation.

The transistor configuration is single and NPN polarity, ideal for switching and amplification tasks in signal processing, power control, and general semiconductor applications across industrial electronics and communication equipment.

Key electrical parameters include a maximum collector-base voltage of 75 V, minimum DC current gain of 35, and maximum power dissipation of 1.5 W. Its high transition frequency of 300 MHz supports high-speed switching needs, and it is engineered to operate reliably in temperature ranges from -55°C to 150°C, satisfying demanding operational environments.

Compliant with RoHS environmental standards and qualified to automotive AEC-Q101 standards under the PZT2222AT1G series, this transistor is suited for both commercial and automotive electronics.

The transistor features a maximum DC collector current of 600 mA for medium power applications. It supports a maximum collector-emitter voltage of 40 V, suitable for low voltage switching. Constructed in a compact SOT-223 surface-mount package for PCB integration.

The device has a high maximum collector-base voltage of 75 V ensuring robust switching performance. It offers a minimum DC current gain (hFE) of 35, providing good amplification. Rated for maximum power dissipation of 1.5 W ensuring thermal reliability.

The maximum transition frequency (ft) is 300 MHz for high frequency applications. Designed to operate between temperatures of -55°C to 150°C for wide environmental tolerance. Pin count is 4, facilitating easy mounting and connection.

This transistor is broadly applicable in electronic components, power control, signal amplification, and automotive electronics manufacturing. Explore more Semiconductors and Bipolar Transistors in EnvMart for additional options and specifications.
