| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.11mm |
| Length | 3.04mm |
| Model | MMBTA56LT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | MMBTA56L |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Maximum Collector Emitter Voltage Vceo | -80V |
| Minimum DC Current Gain hFE | 100 |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | 4V |
| Maximum Collector Base Voltage VCBO | 80V |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Maximum DC Collector Current Idc | -500mA |
| Transistor Configuration | Single |
| Maximum Transition Frequency ft | 50MHz |
| Nexperia Transistor, -500 mA PNP, -80 V, 3-Pin SOT-23Brand | Nexperia |
onsemi MMBTA56LT1G is a small signal PNP transistor designed for surface mount technology, housed in a SOT-23 package with three pins. It can handle a maximum collector current of 500 mA and withstand a maximum collector-emitter voltage of 80 V, making it suitable for general purpose amplification and switching in electronic circuits. This transistor provides reliable performance with a power dissipation rating of 300 mW and a current gain (hFE) of at least 100.
It operates efficiently over a wide temperature range from -55°C to 150°C, making it viable for use in automotive and industrial environments. The device features a maximum transition frequency of 50 MHz, allowing it to handle moderately high-frequency applications. The SOT-23 package facilitates mounting on surface mount PCBs, optimizing board space.
The product is compliant with the automotive standard AEC-Q101, ensuring durability and quality required in automotive electronics. Typical applications include signal amplification, switching circuits, and general purpose use in consumer and industrial electronics.
Compact SOT-23 package suitable for surface mounting. Maximum collector current of 500 mA supports moderate loads. Collector-emitter voltage up to 80 V ensures voltage robustness. Low power dissipation of 300 mW for efficient operation.
High minimum current gain (hFE) of 100 for amplification. Wide operating temperature range from -55°C to 150°C. High transition frequency of 50 MHz for fast switching. Automotive standard AEC-Q101 compliant for reliability.
3-pin configuration for easy PCB integration.
This transistor suits applications in industrial, automotive, and electronic device manufacturing sectors where reliable small signal amplification and switching components are needed. For more precision components and semiconductor devices, explore the extensive onsemi product range available on EnvMart.
