IXYS Three Phase Bridge Rectifier Module Panel Mount Type, 1200 V Peak Reverse Voltage, 1.95 kA Peak Surge VUO160-12NO7

The IXYS VUO160-12NO7 Bridge Rectifier Module is designed as a three-phase power semiconductor device, optimized for converting alternating current (AC) into direct current (DC) efficiently and reliably. Rated for a peak reverse repetitive voltage of 1200 V and forward current up to 175 A, this module is engineered to withstand demanding surge conditions up to 1.95 kA peak non-repetitive forward surge current.

With a panel mount configuration and five pins, the module includes screw terminal connections for secure and stable electrical integration in industrial power electronics, HVAC systems, motor drives, and power supply applications. Its compact housing measures 94 mm in length, 54 mm in width, and 30 mm in height, providing a balanced footprint for effective installation.

The device operates effectively across a broad temperature range from -40°C to 150°C, making it suitable for harsh environments and continuous industrial use. The low forward voltage drop of 1.65 V translates to minimal power losses, improving efficiency and thermal management within power conversion circuits.

Featuring an isolation voltage of 3000 Vrms, this bridge rectifier module ensures electrical isolation essential for safety and compliance in demanding electrical installations. Manufactured in Germany, the IXYS VUO160 Series maintains strict quality and reliability standards, supporting critical industrial, manufacturing, and electrical equipment.

Maximum forward current rating of 175 A ensures high current capacity. Peak surge current rating at 1.95 kA supports transient load conditions. Broad operating temperature range from -40°C to 150°C enables industrial use.

Compact form factor with dimensions 94x54x30 mm eases installation. Low forward voltage drop enhances operational efficiency. Panel mount with screw terminals supports robust electrical connection. 3000 Vrms isolation voltage for safe operation in power systems.

Designed for three-phase AC to DC conversion in power electronics.

This Bridge Rectifier Module is ideal for industrial automation, power control, and energy conversion applications requiring reliable three-phase diode rectification and high surge capacity. Explore EnvMart for more semiconductor power modules from IXYS and related brands.
