IXYS Thyristor Module 1600 V 1.5 kA, 99 A average on-state current, 100 mA max gate trigger current MCO100-16IO1
Specifications
| Country of Origin | India |
|---|---|
| Brand | IXYS |
| Height | 9.6mm |
| Length | 38.2mm |
| Model | MCO100-16IO1 |
| Width | 25.07mm |
| Mount Type | Panel |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-227B |
| Pin Count | 4 |
| Rated Average On-State Current Irms | 99A |
| Repetitive Peak Reverse Voltage VDRM | 1600V |
| Surge Current Rating | 1.5kA |
| Maximum Gate Trigger Current Igt | 100mA |
| Maximum Holding Current Ih | 200mA |
| Maximum Gate Trigger Voltage Vgt | 1.5V |
| Peak On-State Voltage | 1.35V |
| Repetitive Peak Off-State Current | 10mA |
Key Features
- Designed with a SOT-227B 4-pin package for panel mounting.
- Rated average on-state current of 99 A Irms ensures robust conduction capability.
- Maximum gate trigger current of 100 mA and holding current of 200 mA provide reliable control.
- Peak on-state voltage of 1.35 V and max gate trigger voltage of 1.5 V.
- Operates up to 150°C maximum temperature enabling high thermal tolerance.
- Compact dimensions of 38.2 mm length, 25.07 mm width, and 9.6 mm height.
- Repetitive peak off-state current of 10 mA suitable for power regulation circuits.
- Encapsulated with electrically isolated base plate for safe installation.
Product Description
The IXYS MCO100-16IO1 thyristor module is a high power semiconductor device engineered for industrial and commercial applications requiring reliable switching at elevated voltages and currents.
This module features a repetitive peak reverse voltage of 1600 V and a surge current rating of 1.5 kA, making it suitable for demanding power electronic circuits. Housed in a robust SOT-227B package with 4 pins, it is designed for panel mounting with an electrically isolated base plate, facilitating safe and efficient system integration.
The device supports a rated average on-state current of 99 A (Irms) and a peak on-state voltage of 1.35 V, ensuring efficient conduction with minimal losses. Maximum gate trigger current of 100 mA combined with a holding current of 200 mA provides precise control over switching.
Operating safely up to 150°C, this module withstands thermal stresses common in industrial environments such as battery chargers, welding machines, plating equipment, regulated power supplies, and temperature or speed control circuits.
Designed with a SOT-227B 4-pin package for panel mounting. Rated average on-state current of 99 A Irms ensures robust conduction capability. Maximum gate trigger current of 100 mA and holding current of 200 mA provide reliable control.
Peak on-state voltage of 1.35 V and max gate trigger voltage of 1.5 V. Operates up to 150°C maximum temperature enabling high thermal tolerance. Compact dimensions of 38.2 mm length, 25.07 mm width, and 9.6 mm height. Repetitive peak off-state current of 10 mA suitable for power regulation circuits.
Encapsulated with electrically isolated base plate for safe installation. Ideal for use in battery chargers, welders, regulated power supplies, and speed control circuits. UL registered under E 72873 ensuring quality conformity.
This IXYS Thyristor Module provides high reliability and excellent performance in industrial semiconductor applications, enhancing device longevity and operational stability. Explore more semiconductor modules and related power devices in EnvMart's comprehensive Electronics & Electricals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 150°C, allowing it to withstand thermal stresses in industrial applications.
This thyristor module has a rated average on-state current of 99 A (Irms), ensuring robust conduction capability.
The dimensions of this thyristor module are 38.2 mm in length, 25.07 mm in width, and 9.6 mm in height.
The surge current rating for this model is 1.5 kA, allowing it to handle brief high current spikes effectively.
The maximum gate trigger current for this thyristor module is 100 mA, providing reliable control over switching operations.
This model uses a SOT-227B 4-pin package designed for panel mounting, facilitating easy integration into systems.
The peak on-state voltage for this unit is 1.35 V, ensuring efficient conduction with minimal losses.
The maximum holding current for this thyristor module is 200 mA, which aids in maintaining stable operation during switching.
The repetitive peak off-state current for this model is rated at 10 mA, suitable for power regulation circuits.
It is designed for panel mounting, which allows for straightforward installation in various industrial setups.
