IXYS Thyristor Module 1800 V 17 kA 560 A 4-Pin Panel Mount MCO500-18IO1
Specifications
| Country of Origin | India |
|---|---|
| Brand | IXYS |
| Height | 49mm |
| Length | 92mm |
| Model | MCO500-18IO1 |
| Width | 50mm |
| Mount Type | Panel |
| Maximum Operating Temperature | 140°C |
| Pin Count | 4 |
| Rated Average On-State Current Irms | 560A |
| Repetitive Peak Reverse Voltage VDRM | 1800V |
| Surge Current Rating | 17kA |
| Maximum Gate Trigger Current Igt | 300mA |
| Maximum Holding Current Ih | 300mA |
| Maximum Gate Trigger Voltage Vgt | 2V |
| Peak On-State Voltage | 1.3V |
| Repetitive Peak Off-State Current | 40mA |
| Infineon TZ600N12KOFHPSA1, Thyristor 1200V, 600A 250mABrand | Infineon |
| Semikron, SKET400/18E, Thyristor Module SCR, 392A 1800V, 4-Pin A 36Brand | Semikron |
Key Features
- Rated average on-state current of 560 A ensures robust performance.
- Mount type is panel, suitable for stable installation.
- Maximum gate trigger current is 300 mA, enabling controlled triggering.
- Compact dimensions with length 92 mm, width 50 mm, and height 49 mm.
- Maximum operating temperature up to 140°C supports industrial applications.
- Designed with 4-pin configuration for ease of connection.
- Maximum holding current is 300 mA ensuring stable conduction.
- Peak on-state voltage of 1.3 V reduces power losses.
Product Description
IXYS MCO500-18IO1 Thyristor Module is a high power solid-state semiconductor device designed to act as a bistable switch. It operates at a repetitive peak reverse voltage of 1800 V with a surge current rating of 17 kA and an average on-state current of 560 A. The module features a panel mount type and comes equipped with 4 pins for connectivity.
This thyristor module is engineered for industrial applications including battery chargers, welders, plating equipment, regulated power supplies, and temperature and speed control circuits. Its maximum operating temperature of 140°C and compact dimensions (92 mm length, 50 mm width, 49 mm height) make it suitable for demanding environments and space-constrained installations.
The gate trigger characteristics include a maximum gate trigger current of 300 mA and gate trigger voltage of 2 V, ensuring precise control during switching. It also has a maximum holding current of 300 mA and a peak on-state voltage of 1.3 V, contributing to energy efficiency in its operation.
This module is encapsulated with an electrically isolated base plate for safety and durability but does not have automotive standard certifications. It is UL registered (E 72873), assuring quality standards are met for electrical components.
Rated average on-state current of 560 A provides reliable power handling. Panel mount design facilitates easy installation. 4-pin configuration simplifies electrical connections. Surge current rating of 17 kA supports transient loads.
Maximum operating temperature of 140°C allows use in harsh environments. Low peak on-state voltage of 1.3 V improves overall efficiency. Maximum gate trigger current of 300 mA ensures controlled switching. Compact size saves installation space.
Electrically isolated base plate enhances safety. UL registered for compliance and reliability.
This IXYS thyristor module is ideal for industrial, power electronics, and electrical applications requiring robust and reliable switching components. Its technical features are designed to meet high-performance requirements in medium to high power circuits.
Explore more semiconductor and Thyristor Modules on EnvMart to find suitable components for your electronic power control needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature of this module is 140°C, making it suitable for use in harsh industrial environments.
The rated average on-state current for this thyristor module is 560 A, ensuring robust performance in power applications.
This thyristor module has a surge current rating of 17 kA, which supports transient loads in various applications.
The dimensions of this module are 92 mm in length, 50 mm in width, and 49 mm in height, allowing for compact installations.
This model features a 4-pin configuration for ease of connection during installation.
The peak on-state voltage for this module is 1.3 V, which helps to reduce power losses during operation.
The maximum gate trigger current for this thyristor module is 300 mA, enabling controlled triggering during operation.
This module is engineered for industrial applications including battery chargers, welders, plating equipment, and regulated power supplies.
The maximum holding current for this thyristor module is 300 mA, ensuring stable conduction.
The IXYS MCO500-18IO1 uses a panel mount type, facilitating stable installation in various setups.
Yes, this module is UL registered (E 72873), assuring compliance with quality standards for electrical components.
The repetitive peak reverse voltage of this thyristor module is 1800 V, suitable for high voltage applications.
